GMC Sierra 1500 (2000-2012) selectable ride panel switch cluster wiring diagram
This page shows the only wiring diagram for the component.selectable ride panel switch cluster, which is found in the car GMC Sierra 1500 (2000-2012). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
selectable ride panel switch cluster wiring diagram (1 of 1)
A/C COMP RELAY
AUXILIARY POWER OUTLET
B/U LP FUSE
BLK WIRE
BODY CONTROL MODULE
BODY INFLATABLE CONTROL RESTRAINT MODULE I/P MODULE DISABLE SWITCH
BRN WIRE
CLUTCH
DEFOG RELAY
EXC 8.L W/O CALIFORNIA LEV
EXC SEO PNK PNK WIRE
FROM IGN 1 RELAY (DIAGRAM 3 OF 6)
FROM IGN B FUSE (DIAGRAM 1 OF 6)
FUSE
HEATED HEATED OXYGEN OXYGEN SENSOR SENSOR BANK 1 BANK 2 SENSOR 2 SENSOR 2
HEATED OXYGEN SENSOR BANK 1 SENSOR 1
HEATED OXYGEN SENSOR BANK 2 SENSOR 1
I/P RELAY BLOCK (LEFT OF STEERING COLUMN)
IGN E FUSE
IGNITION SWITCH
INSTRUMENT
LEFT I/P FUSE BLOCK (BEHIND LOWER LEFT SIDE OF DASH)
LOCK OFF
NCA WIRE
PARK/NEUTRAL POSITION SWITCH (A/T)
PNK PNK PNK WIRE
PNK PNK WIRE
PNK WIRE
RED WIRE
RR WPR FUSE
RUN WIRE
SELECTABLE RIDE PANEL SWITCH CLUSTER
SEO ACCY FUSE
SEO IGN FUSE
SEO PNK WIRE
SIR FUSE
SWITCH (M/T)
TBC ACCY FUSE
TBC IGN 1 FUSE
UPFITTER BATTERY JUNCTION BLOCK
W/ THERMO CONSOLE
W/O THERMO CONSOLE
WHT WIRE
WINDSHIELD WIPER MOTOR MODULE
WS WPR FUSE
YEL WIRE
Go to component -> 6.0l vin u, power distribution circuit (6 of 6) -> SELECTABLE RIDE PANEL SWITCH CLUSTER
