6.0l vin u, a/t circuit, 4l80-e for GMC Sierra 1500 HD (2001-2006)

1-2 SHIFT SOLENOID 2-3 SHIFT SOLENOID 41 46 54 57 58 59 63 72 74 75 LO REF A/T FLUID PRESSURE MANUAL VALVE POSITION SWITCH AUTOMATIC TRANSMISSION BLK WIRE BLK/WHT WIRE BODY CONTROL MODULE (LOWER LEFT SIDE OF DASH, BELOW STEERING COLUMN) BODY RELAY BLOCK (UNDER LEFT END OF DASH) BRAKE FUSE BRN WIRE BRN/WHT WIRE DK BLU WIRE DK BLU/WHT WIRE DK GRN WIRE ECMB FUSE EXCEPT LIGHT DUTY FLUID TEMP SENSOR FUSE GRY WIRE GRY/BLK WIRE HOT AT ALL TIMES HOT IN HOT IN RUN, BULB TEST, START HOT IN RUN, START INSTRUMENT CLUSTER INSTRUMENT PANEL CLUSTER (IPC) LEFT I/P FUSE BLOCK (LOWER LEFT SIDE OF DASH) LIGHT DUTY LT BLU WIRE LT BLU/WHT WIRE LT GRN WIRE LT GRN/BLK WIRE MALFUNCTION INDICATOR LAMP ORG/ WIRE PARK/NEUTRAL POSITION SWITCH (LEFT SIDE OF TRANSMISSION) PNK PNK WIRE PNK WIRE POWERTRAIN CONTROL MODULE (LEFT FRONT OF ENGINE COMPT) PPL PPL ABS SYSTEM PPL DATA LINK CONNECTOR (UNDER LEFT SIDE OF DASH) PPL PPL PPL/WHT WIRE PRESS CTRL SOLENOID RED WIRE RED/BLK WIRE REV, LO RUN WIRE SENS GND B+ CLS 2 DATA CLS 2 DATA SENS GND PRND B ECT SIG IGN SPLICE PACK STOPLIGHT SWITCH (TOP OF BRAKE PEDAL BRACKET) TCC PWM SOLENOID TRANSFER CASE) (ON TRANSMISSION) UNDERHOOD FUSE BLOCK (LEFT SIDE OF ENGINE COMPT, NEAR BATTERY) VSS ADAPTER W/ TRACTION ASSIST W/O TRACTION ASSIST WHT WIRE YEL WIRE YEL/BLK WIRE
