4.8l vin v, a/t circuit for GMC Sierra 1500 HD (2001-2006)

1 2 6 8 16 19 20 21 40 42 46 47 48 51 62 63 GND TCC PWM PC SOL HI PC SOL LO 1-2 SHIFT SOLENOID 2-3 SHIFT SOLENOID 3-2 SHIFT SOLENOID A/T FLUID PRESSURE MANUAL VALVE POSITION SWITCH AUTOMATIC TRANSMISSION BLK WIRE BLK/WHT WIRE BODY CONTROL MODULE (LOWER LEFT SIDE OF DASH) BRAKE FUSE BRN WIRE BRN/WHT WIRE DATA LINK CONNECTOR (UNDER LEFT SIDE OF DASH) DK BLU WIRE DK BLU/WHT WIRE DK GRN WIRE ENGINE COOLANT TEMPERATURE SENSOR (FRONT OF LEFT CYLINDER HEAD) EXCEPT SEO FLUID TEMP SENSOR FUSE GRY WIRE GRY/BLK WIRE HOT AT ALL TIMES HOT IN HOT IN RUN, ACC, START HOT IN RUN, START I/P FUSE BLOCK (LOWER LEFT SIDE OF DASH) I/P RELAY BLOCK (NEAR LEFT KICK PANEL) IGN 0 FUSE INSTRUMENT PANEL CLUSTER (IPC) IPC/DIC FUSE LT BLU WIRE LT BLU/WHT WIRE LT GRN WIRE LT GRN/BLK WIRE MALFUNCTION INDICATOR LAMP OF TRANSMISSION) ORG/ WIRE ORG/BLK WIRE PARK/NEUTRAL POSITION SWITCH (LEFT SIDE OF TRANSMISSION) PCM B FUSE PNK PNK WIRE PNK WIRE POWER DISTRIBUTION SYSTEM POWERTRAIN CONTROL MODULE (LEFT FRONT OF ENGINE COMPT) PPL PPL/WHT WIRE PRESS CTRL SOLENOID RED WIRE RED/BLK WIRE REV RUN WIRE SEO SPLICE PACK STOPLIGHT SWITCH (TOP OF BRAKE PEDAL BRACKET) TAN WIRE TAN/BLK WIRE TCC PWM SOLENOID TCC SOLENOID TOW/HAUL SWITCH TRANSFER CASE) UNDERHOOD FUSE BLOCK (LEFT SIDE OF ENGINE COMPT) UNDERHOOD FUSE BLOCK (LEFT SIDE OF ENGINE COMPT) PCM 1 FUSE VEHICLE SPEED SENSOR WHT WIRE YEL WIRE YEL/BLK WIRE
