GMC Savana H2500 (2003-2003) Exterior lamps circuit, except cutaway

BLK WIRE BLU WIRE BODY CONTROL MODULE (BEHIND LOWER RIGHT SIDE OF DASH) BODY FUSE BLOCK (BELOW LEFT FRONT SEAT) BODY FUSE BLOCK (BELOW LEFT FRONT SEAT) STOP/ CHMSL FUSE 8 BRN WIRE BRN/WHT WIRE CHMSL/ STOP LAMP SUPPLY VOLTAGE DK BLU WIRE DK BLU/WHT WIRE DK CRUISE CONTROL SYSTEM DK GRN WIRE DK GRN/WHT WIRE DK USED DR TRN MIR FUSE 14 DRIVER'S OUTSIDE REAR VIEW MIRROR (LEFT TURN SIGNAL) DRL ON/OFF SIG FR PRK FUSE 22 FRONT TURN SIGNAL LAMP SUPPLY VOLTAGE GRN WIRE HAZARD SWITCH HEAD OFF HEADLAMP AND PANEL DIMMER SWITCH HOT AT ALL TIMES INSTRUMENT PANEL CLUSTER LEFT LEFT TAIL LAMP ASSEMBLY LEFT TURN SIGNAL IND LOGIC LICENSE LAMP LP PKR FUSE 18 LR STOP/ TURN FUSE 4 LT BLU WIRE LT BLU/WHT WIRE LT GRN/BLK WIRE NCA WIRE NOT USED PARK PARK LAMP RELAY PARK LAMP RLY CTRL HAZARD SW SIG DRL LOW CONTROL PARK LAMP SW ON SIG PASS TRN MIR FUSE 19 PASSENGER'S OUTSIDE REAR VIEW MIRROR (RIGHT TURN SIGNAL) PNK WIRE PROVISIONAL RED/WHT WIRE RIGHT RIGHT TAIL LAMP ASSEMBLY CENTER HIGH MOUNTED STOP LAMP RIGHT TURN SIGNAL IND RR STOP/ TURN FUSE 6 SPLICE PACK TAIL/ STOP/ TURN SIGNAL LAMP TRAILER WIRING (BLUNT CUT) TRLR PRK FUSE 21 TURN SIGNAL SWITCH TURN SIGNAL/ MULTIFUNCTION SWITCH TURN SIGNAL/HAZARD FLASHER MODULE (BEHIND LEFT SIDE OF DASH) UPFTR PRK FUSE 16 WHT WIRE YEL WIRE YEL/BLK WIRE

BATTERY POSITIVE VOLTAGE BLK WIRE BLU WIRE BRN WIRE BTSI/ BU FUSE 38 DK BLU WIRE DK GRN WIRE FLASHER FUSE 14 GRN WIRE GROUND HOT AT ALL TIMES HOT IN RUN OR START IGN E FUSE 22 LEFT FRONT MARKER LAMP LEFT FRONT PARK/ TURN SIGNAL LAMP LEFT TRAILER STOP/ TURN RELAY (ON LEFT OUTER FRAME RAIL, NEAR CENTER OF VEHICLE LH DRL/ TURN FUSE 10 LR STOP/ TURN FUSE 3 LT BLU WIRE PARK/NEUTRAL POSITION SWITCH (LEFT SIDE OF TRANSMISSION) PNK WIRE RED WIRE RED/WHT WIRE RIGHT FRONT MARKER LAMP RIGHT FRONT PARK/ TURN SIGNAL LAMP RIGHT TRAILER STOP/ TURN RELAY (ON LEFT OUTER FRAME RAIL, NEAR CENTER OF VEHICLE RR STOP/ TURN FUSE 4 STOP LAMP SWITCH (ABOVE BRAKE PEDAL) STOP LP FUSE 7 TRAILER AUXILIARY SUPPLY VOLTAGE TRAILER BACKUP LAMPS SUPPLY VOLTAGE TRAILER LEFT REAR TURN/STOP LAMP SUPPLY VOLTAGE TRAILER PARK LAMPS SUPPLY VOLTAGE TRAILER RIGHT REAR TURN/STOP LAMP SUPPLY VOLTAGE TRAILER WIRING (BLUNT CUT) TRL STOP/ TURN FUSE 17 TRLR BU FUSE 5 TRLR FUSE 13 TRLR FUSE 50 UNDERHOOD FUSE BLOCK (LEFT SIDE OF ENGINE COMPARTMENT) UNDERHOOD FUSE BLOCK (LEFT SIDE OF ENGINE COMPARTMENT) RH DRL/ TURN FUSE 9 WHT WIRE WIRING (BLUNT CUT) YEL WIRE
