GMC Savana H2500 (2003-2003) right trailer stop/ turn relay (on left outer frame rail, near center of vehicle Wiring diagram
This page shows the only wiring diagram for the component.right trailer stop/ turn relay (on left outer frame rail, near center of vehicle, which is found in the car GMC Savana H2500 (2003-2003). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram right trailer stop/ turn relay (on left outer frame rail, near center of vehicle (1 of 1)
BATTERY POSITIVE VOLTAGE
BLK WIRE
BLU WIRE
BRN WIRE
BTSI/ BU FUSE 38
DK BLU WIRE
DK GRN WIRE
FLASHER FUSE 14
GRN WIRE
GROUND
HOT AT ALL TIMES
HOT IN RUN OR START
IGN E FUSE 22
LEFT FRONT MARKER LAMP
LEFT FRONT PARK/ TURN SIGNAL LAMP
LEFT TRAILER STOP/ TURN RELAY (ON LEFT OUTER FRAME RAIL, NEAR CENTER OF VEHICLE
LH DRL/ TURN FUSE 10
LR STOP/ TURN FUSE 3
LT BLU WIRE
PARK/NEUTRAL POSITION SWITCH (LEFT SIDE OF TRANSMISSION)
PNK WIRE
RED WIRE
RED/WHT WIRE
RIGHT FRONT MARKER LAMP
RIGHT FRONT PARK/ TURN SIGNAL LAMP
RIGHT TRAILER STOP/ TURN RELAY (ON LEFT OUTER FRAME RAIL, NEAR CENTER OF VEHICLE
RR STOP/ TURN FUSE 4
STOP LAMP SWITCH (ABOVE BRAKE PEDAL)
STOP LP FUSE 7
TRAILER AUXILIARY SUPPLY VOLTAGE
TRAILER BACKUP LAMPS SUPPLY VOLTAGE
TRAILER LEFT REAR TURN/STOP LAMP SUPPLY VOLTAGE
TRAILER PARK LAMPS SUPPLY VOLTAGE
TRAILER RIGHT REAR TURN/STOP LAMP SUPPLY VOLTAGE
TRAILER WIRING (BLUNT CUT)
TRL STOP/ TURN FUSE 17
TRLR BU FUSE 5
TRLR FUSE 13
TRLR FUSE 50
UNDERHOOD FUSE BLOCK (LEFT SIDE OF ENGINE COMPARTMENT)
UNDERHOOD FUSE BLOCK (LEFT SIDE OF ENGINE COMPARTMENT) RH DRL/ TURN FUSE 9
WHT WIRE
WIRING (BLUNT CUT)
YEL WIRE
Go to component -> Exterior lamps circuit, except cutaway (2 of 2) -> RIGHT TRAILER STOP/ TURN RELAY (ON LEFT OUTER FRAME RAIL, NEAR CENTER OF VEHICLE
