GMC Savana H2500 (2003-2003) right front door tweeter speaker Wiring diagram
This page shows the only wiring diagram for the component.right front door tweeter speaker, which is found in the car GMC Savana H2500 (2003-2003). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram right front door tweeter speaker (1 of 1)
2 1 VOICE LOW REF VOICE SIGNAL
ANTENNA
ANTENNA IN
BLK/WHT WIRE
CELL PHONE REF CELL PHONE SIG
CLASS 2 DATA
COMPUTER DATA LINES SYSTEM
DK BLU WIRE
DK GRN WIRE
HOT AT ALL TIMES
LEFT FRONT DOOR SPEAKER
LEFT FRONT DOOR TWEETER SPEAKER
LF SPEAKER (+) LF SPEAKER (-) RR SPEAKER (-) RR SPEAKER (+) GROUND BATTERY
LR SPEAKER + LR SPEAKER - RF SPEAKER - RF SPEAKER +
LT BLU WIRE
LT BLU/BLK WIRE
NCA WIRE
NOT USED
ORG/ WIRE
RADIO
RADIO BAT FUSE 1
RED/WHT WIRE
RIGHT FRONT DOOR SPEAKER
RIGHT FRONT DOOR TWEETER SPEAKER
TAN WIRE
UNDERHOOD FUSE BLOCK
WHT WIRE
Go to component -> Radio circuit, without rear seat audio -> RIGHT FRONT DOOR TWEETER SPEAKER
