GMC Savana H2500 (2003-2003) pcm bat fuse 2 Wiring diagram
This page shows the only wiring diagram for the component.pcm bat fuse 2, which is found in the car GMC Savana H2500 (2003-2003). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram pcm bat fuse 2 (1 of 1)
ABS FUSE 48
AUX PWR FUSE 29 IPC FUSE 31
AUXILIARY POWER OUTLET
BATTERY
BLK WIRE
BLOW FUSE 51
BLOWER MOTOR RESISTOR ASSEMBLY
BODY CONTROL MODULE (BCM)
BODY FUSE BLOCK
CIGAR FUSE 30
CIGAR LIGHTER
DATA LINK CONNECTOR (DLC)
DRIVER SEAT ADJUSTER SWITCH (IF EQUIPPED)
FLASHER FUSE 14
FROM UNDERHOOD FUSE BLOCK (RFA FUSE 20) (DIAGRAM 1 OF 6)
FRONT PASSENGER SEAT ADJUSTER SWITCH (IF EQUIPPED)
FUSIBLE LINK B
FUSIBLE LINK C
GENERATOR
HVAC CONTROL ASSEMBLY
INSTRUMENT PANEL CLUSTER (IPC)
LEFT TRAILER STOP/TURN RELAY (IF EQUIPPED)
MEGA FUSE 65
ORG/ WIRE
PCM BAT FUSE 2
POWERTRAIN CONTROL MODULE (PCM) ELECTRONIC BRAKE CONTROL MODULE (EBCM)
PWR SEAT CIRCUIT BREAKER 60
RADIO
RADIO BAT FUSE 1 TRL STOP/TRN FUSE 17
RED WIRE
RED/BLK WIRE
RED/WHT WIRE
REMOTE CONTROL DOOR LOCK RECEIVER (IF EQUIPPED)
RFA FUSE 20
RR DEF/HTD MIR FUSE 8
SPARE FUSE 64
STARTER
STOP LAMP SWITCH
STOP LP FUSE 7
TBC 2 FUSE 18
TBC 3 FUSE 16
TBC 4 FUSE 11
TBC FUSE 19
TO BODY FUSE BLOCK (DOOR LKS FUSE 15) (DIAGRAM 2 OF 6)
TO UNDERHOOD FUSE BLOCK (CAN VENT FUSE 34) (DIAGRAM 2 OF 6)
TO UNDERHOOD FUSE BLOCK (TBC FUSE 19) (DIAGRAM 1 OF 6)
TRLR FUSE 13
TRLR FUSE 50
TURN SIGNAL/ HAZARD FLASHER MODULE
UNDERHOOD FUSE BLOCK
VEHICLE COMMUNICATION INTERFACE MODULE (VCIM) (IF EQUIPPED)
W/ REAR WINDOW DEFOGGER/ HEATED MIRRORS
Go to component -> Power distribution circuit (1 of 6) -> PCM BAT FUSE 2
