GMC Savana H2500 (2003-2003) left up Wiring diagram
This page shows the only wiring diagram for the component.left up, which is found in the car GMC Savana H2500 (2003-2003). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram left up (1 of 1)
BLK WIRE
BODY CONTROL MODULE (LOWER RIGHT SIDE OF DASH)
BODY FUSE BLOCK (ON LOWER LEFT KICK PANEL)
BRN WIRE
DK BLU WIRE
DK GRN WIRE
DRIVER WINDOW MOTOR
DRIVER WINDOW SWITCH
FRONT PASSENGER WINDOW MOTOR
FRONT PASSENGER WINDOW SWITCH
HOT AT ALL TIMES
LEFT UP
ORG/ WIRE
PWR WND CIRCUIT BREAKER 34
RIGHT DN
TAN WIRE
UP DN
WHT WIRE
WND RAP RELAY 23
Go to component -> Power windows circuit -> LEFT UP
