GMC Savana H2500 (2003-2003) heat heat/def def Wiring diagram
This page shows the only wiring diagram for the component.heat heat/def def, which is found in the car GMC Savana H2500 (2003-2003). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram heat heat/def def (1 of 1)
AIR TEMPERATURE ACTUATOR (BEHIND RIGHT SIDE OF DASH)
AUXILIARY BLOWER MOTOR (IF EQUIPPED)
AUXILIARY BLOWER MOTOR RESISTOR
AUXILIARY BLOWER MOTOR SWITCH (IF EQUIPPED)
BLK WIRE
BLOW FUSE 51
BLOWER MOTOR (RIGHT REAR OF ENGINE COMPT)
BLOWER MOTOR RESISTOR ASSEMBLY (RIGHT REAR OF ENGINE COMPT)
BODY FUSE BLOCK (BELOW LEFT FRONT SEAT)
BRN WIRE
BRN/WHT WIRE
DK BLU WIRE
HEAT HEAT/DEF DEF
HOT AT ALL TIMES
HOT IN
HVAC 1 FUSE 9
HVAC CONTROL ASSEMBLY
HVAC FUSE 10
LT BLU WIRE
MED LO OFF
OFF VENT BI-LEV
ORG/ WIRE
PPL
RED WIRE
RED/BLK WIRE
RED/WHT WIRE
RR BLOWER FUSE 13
RUN WIRE
SPLICE PACK (BOTTOM OF LEFT "B" PILLAR)
TAN WIRE
UNDERHOOD FUSE BLOCK (LEFT SIDE OF ENGINE COMPT)
WHT WIRE
YEL WIRE
Go to component -> Heater circuit -> HEAT HEAT/DEF DEF
