GMC Savana H1500 (2003-2013) left side rear access panel relay 1 Wiring diagram
This page shows the only wiring diagram for the component.left side rear access panel relay 1, which is found in the car GMC Savana H1500 (2003-2013). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram left side rear access panel relay 1 (1 of 1)
7 CM FROM BREAKOUT FOR REAR FUSE BLOCK)
APPROX 15 CM FROM REAR FUSE BLOCK)
APPROX 8 CM FROM REAR FUSE BLOCK)
AUXILIARY HIGH SPEED BLOWER MOTOR RELAY
AUXILIARY LOW SPEED BLOWER MOTOR RELAY
AUXILIARY MED SPEED BLOWER MOTOR RELAY
BLUNT CUT)
DOME FLUORESCENT WORK LAMP RELAY
DOME FLUORESCENT WORK LAMPS FUSE 2
FROM BODY FUSE BLOCK (AUXILIARY 1 FUSE 32) (DIAGRAM 5 OF 6)
FROM BODY FUSE BLOCK (RR BLOWER FUSE 13) (DIAGRAM 5 OF 6)
LEFT SIDE FRONT ACCESS PANEL RELAY 5
LEFT SIDE REAR ACCESS PANEL RELAY 1
ORG/ WIRE
PANEL ACTUATOR FUSE 3
PROVISIONAL
REAR FUSE BLOCK (ON LEFT "B" PILLAR)
RED WIRE
RED/BLK WIRE
RED/WHT WIRE
RIGHT SIDE ACCESS PANEL RELAY 6
W/ AUXILIARY HVAC
W/ COMMERCIAL OPTION W/O CUTAWAY
W/O AUXILIARY HVAC
W/O COMMERCIAL OPTION
W/O COMMERCIAL OPTION W/ CUTAWAY
Go to component -> Power distribution circuit (6 of 6) -> LEFT SIDE REAR ACCESS PANEL RELAY 1
