GMC Savana G3500 (1996-2013) Warning system circuits

BASE BATTERY INPUT KEY-IN SW INPUT FASTEN BELTS OUT GROUND PNK IGNITION ON INPUT WIRE BLK WIRE BLK/WHT WIRE CONVENIENCE CENTER (UNDER LEFT SIDE OF DASH) DK GRN WIRE DRIVER DOOR JAMB SWITCH EXCEPT BASE GAUGES FUSE 4 GRY WIRE HAZARD FUSE 5 HOT AT ALL TIMES HOT IN PARK OR HEAD HOT IN RUN OR START I/P FUSE BLOCK (ON LOWER LEFT KICK PANEL) IGNITION KEY ALARM SWITCH ILLUM MIR FUSE 14 INFLATABLE RESTRAINT SENSING, DIAGNOSTIC MODULE (SDM) INSTRUMENT CLUSTER SYSTEM INSTRUMENT PANEL CLUSTER (IPC) LIGHTS ON INPUT LT GRN WIRE MULTI-FUNCTION ALARM MODULE (UNDER LEFT SIDE OF DASH) NCA WIRE ORG/ WIRE PNK WIRE SAFETY BELT INPUT SAFETY BELT LAMP SPEED INPUT TAN WIRE YEL WIRE
