6.5l vin f, a/t circuit for GMC Savana G3500 (1996-2013)

1-2 SS 2-3 SS A/T FLUID PRESSURE MANUAL VALVE POSITION SWITCH ANTI-LOCK BRAKES SYSTEM (ELECTRONIC BRAKE CONTROL MODULE) APP 3 SIG SENS GROUND A/T ISS SENS HI AUTOMATIC TRANSMISSION AUTOMATIC TRANSMISSION INPUT SHAFT SPEED SENSOR (ON LEFT SIDE OF TRANSMISSION) BLK WIRE BLK/WHT WIRE BRN WIRE BRN/WHT WIRE DATA LINK CONNECTOR (DLC) (PARTIAL) (UNDER LEFT SIDE OF DASH) DK BLU WIRE DK BLU/WHT WIRE DK GRN WIRE DK GRN/WHT WIRE ECM I FUSE ECM-B FUSE ENGINE CONTROLS SYSTEM ENGINE CONTROLS SYSTEM (FUEL PUMP RELAY) ENGINE COOLANT TEMPERATURE (ECT) SENSOR (ON TOP FRONT OF ENGINE) GAUGES FUSE 4 GRY WIRE HOT AT ALL TIMES HOT IN OFF, RUN OR START HOT IN RUN OR START I/P FUSE BLOCK (ON LEFT LOWER KICK PANEL) INSTRUMENT CLUSTER LT BLU WIRE LT BLU/WHT WIRE LT GRN WIRE LT GRN/BLK WIRE MALFUNCTION INDICATOR LAMP ORG/ WIRE PNK PNK WIRE PNK WIRE POWERTRAIN CONTROL MODULE (PCM) (BEHIND CENTER OF DASH) PPL PPL PNK PNK WIRE PPL/WHT WIRE PRESSURE CONTROL SOLENOID VALVE RED WIRE RED/BLK WIRE SOUND SYSTEMS (RADIO) STOP FUSE 1 STOPLAMP SWITCH TAN WIRE TAN/WHT WIRE TCC PWM SOL TCC/STOPLAMP SWITCH (BEHIND DASH, ON BRAKE PEDAL SUPPORT) TRANS FLUID TEMP SENSOR TRANS FUSE 20 UNDERHOOD FUSE/RELAY CENTER (ON LEFT SIDE OF ENGINE COMPT) VEHICLE SPEED SENSOR (VSS) (ON LEFT SIDE OF TRANSMISSION) VEHICLE SPEED SENSOR BUFFER MODULE (UNDER GLOVE BOX) WHT WIRE WHT/BLK WIRE YEL WIRE YEL/BLK WIRE
