GMC Savana Camper Special G3500 (1996-2011) Courtesy lamps circuit, without upfitter package

AUXILIARY 1 FUSE 32 BLK WIRE BODY CONTROL MODULE (BCM) (BEHIND LOWER RIGHT SIDE OF DASH) BODY FUSE BLOCK (UNDER LEFT FRONT SEAT) CARGO CARGO DOOR LATCH ASSEMBLY CTSY CTSY LPS SUPPLY BATTERY DK BLU/WHT WIRE DOME DOME DEFEAT DOME HNDL DOOR OPEN SW SIG REAR DOOR AJAR CTSY LAMPS ON SIG LF DOOR SW SIG DRIVER DOOR LATCH ASSEMBLY FL WORK LMP SIG FL WORK LMP CTRL GRY/BLK WIRE HEADLAMP AND PANEL DIMMER SWITCH HNDL HOT AT ALL TIMES LEFT REAR DOOR JAMB SWITCH LT GRN WIRE NOT USED ORG/ WIRE PASSENGER DOOR LATCH ASSEMBLY POWER PPL PPL DEFEAT SW SIG REAR DOME LAMP RED WIRE RED/WHT WIRE RIGHT REAR DOOR JAMB SWITCH TAN WIRE TBC 2 FUSE 18 UNDERHOOD FUSE BLOCK (LEFT SIDE OF ENGINE COMPT) W/ POWER DOOR LOCKS W/O POWER DOOR LOCKS YEL/BLK WIRE

BLK WIRE DK BLU/WHT WIRE DOME DOME FLOUR- ESCENT FUSE 2 DOME FLUORESCENT WORK LAMP 1 DOME FLUORESCENT WORK LAMP 2 DOME FLUORESCENT WORK LAMP RELAY (AT LEFT "B" PILLAR) DOME READING FRONT COURTESY/ READING LAMPS FRONT COURTESY/ READING LIGHT GRY/BLK WIRE HARNESS, 12 CM FROM LEFT FRONT DOME FLUORESCENT WORK LAMP CONNECTOR) LEFT FRONT DOME FLUORESCENT WORK LAMP LEFT REAR DOME FLUORESCENT WORK LAMP LEFT VANITY MIRROR LAMP MID COURTESY/ READING LAMPS NCA WIRE ORG/ WIRE READING REAR COURTESY READING LAMPS REAR FUSE BLOCK (ON LEFT "B" PILLAR) RED WIRE RIGHT DOME FLUORESCENT WORK LAMP RIGHT VANITY MIRROR LAMP UNDERHOOD LAMP W/ CARGO/CUTAWAY W/O CARGO/CUTAWAY 2 3 4 W/O VANITY MIRRORS W/ VANITY MIRRORS
