Exterior lamps circuit, with sealed beam headlamps for GMC Savana Camper Special G3500 (1996-2011)

BLK WIRE BLK/WHT WIRE BLU WIRE BRN WIRE CENTER HIGH MOUNTED STOP LAMP (CHMSL) CRUISE CONTROL SYSTEM DK BLU WIRE DK DK DK GRN WIRE HAZ SW TN SW HAZARD HAZARD FUSE 5 HEADLAMP SWITCH HOT AT ALL TIMES HOT IN RUN OR START I/P FUSE BLOCK TURN- B/U FUSE 16 I/P RELAY CENTER (UNDER LEFT SIDE OF DASH) INSTRU- MENT CLUSTER RIGHT TURN IND. LEFT LEFT FRONT PARK/TURN SIGNAL LAMP LEFT FRONT SIDE MARKER LAMP LEFT REAR PARK/ STOP LAMP LEFT REAR PARK/ TURN LAMP LEFT TURN IND LT BLU WIRE LT GRN WIRE NORMAL OFF HEAD PARK ORG/ WIRE PARK LPS FUSE 9 PNK WIRE PPL RIGHT RIGHT FRONT SIDE MARKER LAMP RIGHT FRONT PARK/TURN SIGNAL LAMP RIGHT REAR PARK/ STOP LAMP LICENSE LAMP RIGHT REAR PARK/ TURN LAMP STOP FUSE 1 TCC/ STOP LAMP SWITCH (BEHIND DASH, ON TURN PWR HAZ PWR FLSHR OUT GND TURN/ HAZARD SWITCH TURN/HAZARD LAMP FLASHER W/ OPTIONAL TRAILER WIRING PACKAGE (RIGHT REAR OF INTERIOR) WHT WIRE YEL WIRE
