GMC Rally G3500 (1985-1996) Exterior light circuit, cutaway chassis

BACKUP LAMP SWITCH (ON STEERING COLUMN) BLK WIRE BLU WIRE BRN WIRE DK BLU WIRE DK GRN WIRE FUSE BLOCK (BEHIND LEFT SIDE OF I/P) G# N/A (IN REAR LAMPS HARNESS) GRN WIRE HAZARD HAZARD FLASHER HEAD HEADLIGHT SWITCH HOT AT ALL TIMES HOT IN RUN OR START INSTRUMENT CLUSTER LEFT BACKUP LAMP RIGHT BACKUP LAMP LEFT FRONT MARKER LAMP LEFT LICENSE LAMP LEFT PARK LAMP LEFT TAIL/STOP TURN LAMP LEFT TURN INDICATOR LT BLU WIRE LT LT NORMAL OFF ORG/ WIRE PARK PPL PROVISIONS FOR CLEARANCE LAMPS PROVISIONS FOR REAR MARKER LAMPS RIGHT FRONT MARKER LAMP RIGHT FRONT PARK/ TURN LAMP LEFT FRONT PARK/ TURN LAMP RIGHT LICENSE LAMP RIGHT PARK LAMP RIGHT TAIL/STOP TURN LAMP RIGHT TURN INDICATOR STOP/ HAZ FUSE STOPLAMP SWITCH (ON BRAKE PEDAL SUPPORT BRACKET) TAIL LPS FUSE TURN LEFT TURN RIGHT TURN SIGNAL FLASHER TURN-B/U FUSE TURN/HAZARD SWITCH (ON MULTI- FUNCTION LEVER) WHT WIRE YEL WIRE
