GMC Rally G2500 (1985-1995) engine coolant level indicator module Wiring diagrams
This page contains all the electrical diagrams for the component. engine coolant level indicator module, in which he is found in the car GMC Rally G2500 (1985-1995). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
engine coolant level indicator module wiring diagram (1 of 2)
1995 VFTC
ANTI-LOCK BRAKE PUMP MOTOR
AUDIO ALARM MODULE
BLK WIRE
BLK/WHT WIRE
BODY BUILDER FRONT MARKER LAMP
BODY BUILDER REAR MARKER LAMP
BRAKE/ TRANSMISSION SHIFT INTERLOCK SOLENOID SAFETY BELT RETRACTOR SWITCH
CIGARETTE LIGHTER
COOLANT LEVEL INDICATOR
CRUISE CONTROL SERVO
DATA LINK CONNECTOR
DAYTIME RUNNING LAMPS MODULE
DAYTIME RUNNING LAMPS RELAY
ENGINE COOLANT LEVEL INDICATOR MODULE
FLOW SWITCH (BRAKES)
FUEL HEATER
GLOW PLUG LAMP INDICATOR
GLOW PLUG MODULE
HD TRAILER TOW PACKAGE REAR A/C BLOWER MOTOR
HEATER CONTROL LAMP
INSTRUMENT CLUSTER
LEFT BACKUP LAMP
LEFT GRID DEFOGGER
LEFT REAR SIDE MARKER LAMP
LEFT SIDE MARKER LAMP
LEFT TAIL/ STOP AND TURN LAMP SIGNAL
LIGHT SWITCH
MODULE
NCA WIRE
POWERTRAIN CONTROL MODULE (PCM)
RADIO
RIGHT BACKUP LAMP
RIGHT GRID DEFOGGER
RIGHT REAR SIDE MARKER LAMP
RIGHT SIDE MARKER LAMP
RIGHT TAIL/ STOP AND TURN LAMP SIGNAL
TAN/WHT WIRE
VEHICLE SPEED SENSOR BUFFER
W/ DIESEL ENGINES
WATER IN-FUEL SENSOR
WHT WIRE
WINDSHIELD WASHER PUMP
WINDSHIELD WIPER MOTOR MODULE
Go to component -> Ground distribution circuit (2 of 2) -> ENGINE COOLANT LEVEL INDICATOR MODULE
engine coolant level indicator module wiring diagram (2 of 2)
1995 VFTC
4.3L, 7.4L ONLY
5.7L, 6.5L ONLY
ACCY
ALT FUSE
AUTO APPLY PARK BRAKE
BLK WIRE
BLK/ORG WIRE
BRAKE PRESSURE WARNING SWITCH (REAR OF ENGINE COMPT)
BRN/WHT WIRE
BULB TEST
COOLANT TEMP GAUGE
DAYTIME RUNNING LAMPS MODULE
DAYTIME RUNNING LIGHTS IND
DIESEL
DIESEL ONLY
DK BLU (OR BRN) WIRE
DK BLU WIRE
DK BLU/WHT WIRE
DK GRN WIRE
DK GRN/BLK WIRE
ECM-CRNK FUSE
ENGINE CONTROLS OR TRANSMISSIONS SYSTEM
ENGINE COOLANT LEVEL INDICATOR MODULE
ENGINE COOLANT LEVEL INDICATOR PROBE (IN RADIATOR) (FRONT OF ENGINE)
ENGINE COOLANT TEMPERATURE SENDER (LEFT SIDE OF ENGINE)
FASTEN BELTS IND.
FUEL GAUGE
FUEL PUMP, SENDER (IN FUEL TANK)
FUEL PUMP/ OIL PRESSURE SWITCH, SENDER (LEFT SIDE OF ENGINE)
FUSE BLOCK
FUSIBLE LINK
GAUGES FUSE
GLOW PLUG CONTROLLER (REAR OF ENGINE)
GLOW PLUGS IND. (DIESEL)
GRY WIRE
GRY/RED WIRE
HEADLIGHTS SYSTEM
HI-BEAM IND
HOT IN RUN
HOT IN RUN, BULB TEST OR START
I/P GROUND (IN I/P HARNESS)
IGNITION SWITCH
ILLUM. LAMPS
INSTRUMENT CLUSTER
LEFT TURN IND
LOW COOLANT IND. (DIESEL)
LT BLU WIRE
LT BLU/BLK WIRE
LT GRN WIRE
MAL- FUNCTION IND
OFF
OIL PRESS GAUGE
ORG/ WIRE
PARK BRAKE IND
PARK BRAKE WARNING SWITCH (PARK BRAKE SUPPORT BRACKET)
PNK WIRE
PNK/BLK WIRE
POWERTRAIN CONTROL MODULE (LEFT SIDE OF SHIPPING PANEL)
RIGHT FRAME RAIL)
RIGHT TURN IND
RUN WIRE
SERVICE BRAKES IND.
SERVICE TRANS- MISSION IND.
SPEED- OMETER
TAN WIRE
TAN/WHT WIRE
TRANSMISSIONS SYSTEM
VEHICLE SPEED SENSOR (REAR OF TRANSMISSION)
VEHICLE SPEED SENSOR BUFFER (BEHIND RIGHT SIDE OF I/P)
VOLT- METER
W/ DRL
W/ DRL LOCK
W/O DRL
WARNING SYSTEMS
WATER IN FUEL IND. (DIESEL)
WATER-IN-FUEL SENSOR (DIESEL ONLY) (REAR OF ENGINE)
WHT WIRE
YEL WIRE
YEL/BLK WIRE
Go to component -> Instrument cluster circuit, commercial chassis -> ENGINE COOLANT LEVEL INDICATOR MODULE
