6.5l (vin s), transmission circuit, 4l80-e for GMC Pickup K3500 (1985-2000)

1-2 SHIFT SOL ACCELERATOR PEDAL POSITION (APP) MODULE (TOP OF ACCE- LERATOR BRACKET) APP #3 APP #3 SENSOR SIG APP 1 BLK WIRE BLK/WHT WIRE BLK/YEL WIRE BRN WIRE BRN/WHT WIRE DATA LINK CONNECTOR (BELOW LEFT SIDE OF I/P) DK BLU WIRE DK BLU/WHT WIRE DK GRN WIRE ECM IGN FUSE ELECTRONIC 4-SPEED AUTOMATIC OVERDRIVE TRANSMISSION ENGINE COOLANT TEMPERATURE (ECT) SENSOR (RIGHT SIDE OF ENGINE) FUSIBLE LINK GRY WIRE GRY/RED WIRE HOT AT ALL TIMES HOT IN RUN, BULB TEST OR START HOT IN START OR RUN FUSE BLOCK TRANS FUSE IGNITION FEED TCC DIAGNOSTIC REQUEST LT BLU WIRE LT BLU/WHT WIRE LT GRN WIRE LT GRN/BLK WIRE ORG/ WIRE ORG/BLK WIRE PNK WIRE PNK/BLK WIRE POWERTRAIN CONTROL MODULE PPL PPL APP #2 PPL TCC/BRAKE SW PPL/WHT WIRE PRESSURE CONTROL SOLENOID RANGE MODE SELECTOR RED WIRE RED/BLK WIRE SPEED SENSOR (LEFT REAR SIDE OF TRANSMISSION) TAN WIRE TCC SOL 2-3 SHIFT SOL TCC/ BRAKE SWITCH (ON BRAKE PEDAL SUPPORT BRACKET) TRANS FLUID TEMP (TFT) SENSOR TRANS INPUT SPD SIG LO TRANSFER CASE SWITCH TRANSMISSION INPUT SPEED SENSOR (LEFT SIDE OF TRANSMISSION) VEHICLE SPEED SENSOR BUFFER (UNDER RIGHT END OF I/P) WHT WIRE WHT/BLK WIRE YEL WIRE YEL/BLK WIRE
