GMC Pickup C3500 (1985-2000) master window switch wiring diagram
This page shows the only wiring diagram for the component.master window switch, which is found in the car GMC Pickup C3500 (1985-2000). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
master window switch wiring diagram (1 of 1)
BLK WIRE
BRN WIRE
CONVENIENCE CENTER
DK BLU WIRE
DK BLU/WHT WIRE
DK GRN WIRE
FUSE BLOCK
GAUGES FUSE
GRY WIRE
HOT IN RUN OR START
LEFT FRONT POWER WINDOW MOTOR
LEFT FRONT WINDOW UP
LEFT REAR POWER WINDOW MOTOR
LEFT REAR WINDOW DN UP
LEFT REAR WINDOW SWITCH
LT GRN WIRE
MASTER WINDOW SWITCH
PNK WIRE
PNK/BLK WIRE
PPL
PPL PPL
PPL/WHT WIRE
RIGHT FRONT POWER WINDOW MOTOR
RIGHT FRONT WINDOW DN UP
RIGHT FRONT WINDOW SWITCH
RIGHT REAR POWER WINDOW MOTOR
RIGHT REAR WINDOW SWITCH
RIGHT REAR WINDOW UP
SWITCH ILLUMINATION LAMP
TAN WIRE
UP DN
Go to component -> Power window circuit, crew cab -> MASTER WINDOW SWITCH
