Endgate circuit, inner for GMC Hummer EV I (2021-2024)

AUTOSAR CAN BUS (-) 9 SERIAL DATA BATT +VE VOLTAGE BLK WIRE BLU/GRN WIRE BLU/VIO WIRE BLU/YEL WIRE BODY CONTROL MODULE (UNDER LEFT SIDE OF DASH) COMPUTER DATA LINES SYSTEM DISPLAY GROUND GROUND PICKUP BOX ENDGATE LATCH RELAY HIGH MOUNT STOP LAMP HOT AT ALL TIMES INSTRUMENT PANEL CLUSTER CONTROL MODULE LEFT INSTRUMENT PANEL WIRING HARNESS JUNCTION BLOCK LEFT MINOR ENDGATE AJAR SIG LEFT PICKUP BOX AUXILIARY ENDGATE LATCH LOGIC MINOR ENDGATE HI RLY CTRL MINOR ENDGATE LOW RLY CTRL MINOR ENDGATE REL SWITCH DISCRETE SIGNAL EXTERIOR NCA WIRE PICKUP BOX AUXILIARY ENDGATE LATCH RELAY PICKUP BOX ENDGATE LATCH HANDLE RED/GRN WIRE RED/GRY WIRE RIGHT INSTRUMENT PANEL WIRING HARNESS JUNCTION BLOCK RIGHT MINOR ENDGATE AJAR SIG RIGHT PICKUP BOX AUXILIARY ENDGATE LATCH VIO WIRE WHT/BRN WIRE WHT/GRN WIRE WHT/GRY WIRE YEL WIRE YEL/BLK WIRE YEL/BLU WIRE
