GMC Hummer EV I (2021-2024) windshield outside moisture/ ambient light and humidity sensor Wiring diagram
This page shows the only wiring diagram for the component.windshield outside moisture/ ambient light and humidity sensor, which is found in the car GMC Hummer EV I (2021-2024). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram windshield outside moisture/ ambient light and humidity sensor (1 of 1)
ACCESSORY POWER RECEPTACLE SWITCH
AUTOMATED DRIVING MAPPING MODULE
BLK WIRE
BLK/WHT WIRE
BLU/RED WIRE
BODY CONTROL MODULE
COMMUNICATION CENTER CALL SWITCH
CRUISE CONTROL SWITCH
DATA LINK CONNECTOR
DIMMER SWITCH
DRIVER MONITORING SYSTEM MODULE
FORWARD COLLISION ALERT DISPLAY
GRN/ORG WIRE
INSIDE REAR VIEW MIRROR
INSTRUMENT PANEL CLUSTER CONTROL MODULE
LEFT FRONT FLOOR COURTESY LAMP
NCA WIRE
ON/OFF VEHICLE SWITCH
PARKING BRAKE CONTROL SWITCH
RADIO CONTROL
STEERING COLUMN CONTROL MODULE
STEERING WHEEL AIR BAG COIL
STEERING WHEEL DRIVER MONITORING SYSTEM MODULE
STEERING WHEEL HORN CONTACT
STEERING WHEEL RADIO CONTROL SWITCH
STEERING WHEEL RADIO FAVORITES SWITCH
STEERING WHEEL RADIO VOLUME SWITCH
TRAILER BRAKE CONTROL SWITCH
TURN SIGNAL SWITCH
WINDSHIELD FRONT VIEW CAMERA
WINDSHIELD OUTSIDE MOISTURE/ AMBIENT LIGHT AND HUMIDITY SENSOR
Go to component -> Ground distribution circuit (4 of 8) -> WINDSHIELD OUTSIDE MOISTURE/ AMBIENT LIGHT AND HUMIDITY SENSOR
