GMC Hummer EV I (2021-2024) w/ tailgate assist lighting accessory Wiring diagram
This page shows the only wiring diagram for the component.w/ tailgate assist lighting accessory, which is found in the car GMC Hummer EV I (2021-2024). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram w/ tailgate assist lighting accessory (1 of 1)
BATTERY CHARGER COUPLER
BATTERY ENERGY CONTROL MODULE 1
BLK WIRE
BLK/WHT WIRE
CHARGE PORT DOOR AJAR SWITCH
CHARGE PORT HOUSING
CHARGE PORT HOUSING LAMP
HIGH MOUNT STOP LAMP
IMAGE PROCESSING MODULE
LEFT CARGO LAMP PICKUP BOX AUXILIARY ENDGATE STEP
LEFT PICKUP BOX AUXILIARY ENDGATE LATCH
LEFT PICKUP BOX ENDGATE LATCH
LEFT REAR BODY STRUCTURE STOP LAMP
LEFT REAR LICENSE PLATE LAMP
LEFT SHORT RANGE RADAR REAR SENSOR
LEFT SHORT RANGE RADAR REAR SIDE SENSOR
LOGIC
NCA WIRE
PARKING ASSIST CONTROL MODULE
PEDESTRIAN ALERT CONTROL MODULE
PICKUP BOX ENDGATE LATCH HANDLE
RIGHT CARGO LAMP
RIGHT CARGO LAMP PICKUP BOX AUXILIARY ENDGATE STEP
RIGHT PICKUP BOX AUXILIARY ENDGATE LATCH
RIGHT REAR LICENSE PLATE LAMP
RIGHT SHORT RANGE RADAR REAR SENSOR
RIGHT SHORT RANGE RADAR REAR SIDE SENSOR
SUSPENSION CONTROL MODULE
TRAILER TIRE PRESSURE INDICATOR MODULE
UHF LOW ENERGY REMOTE CONTROL ACCESS SENSOR TRANSCEIVER 2
UHF LOW ENERGY REMOTE CONTROL ACCESS SENSOR TRANSCEIVER 4
UHF LOW ENERGY REMOTE CONTROL ACCESS SENSOR TRANSCEIVER 5
VEHICLE DYNAMICS SENSOR
W/ TAILGATE ASSIST LIGHTING ACCESSORY
W/O TAILGATE ASSIST LIGHTING ACCESSORY
WHT WIRE
Go to component -> Ground distribution circuit (8 of 8) -> W/ TAILGATE ASSIST LIGHTING ACCESSORY
