GMC Hummer EV I (2021-2024) single gnd Wiring diagram
This page shows the only wiring diagram for the component.single gnd, which is found in the car GMC Hummer EV I (2021-2024). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram single gnd (1 of 1)
BATTERY POSITIVE VOLT
BLK/WHT WIRE
BLU/BRN WIRE
BLU/ORG WIRE
BLU/WHT WIRE
BLU/YEL WIRE
CAN BUS (+) 5 SERIAL DATA
CAN BUS (-) 2 SERIAL DATA
COAX
COMPUTER DATA LINES SYSTEM
DR ILL LAMP 1 CTRL
DR ILL LAMP 2 CTRL
DR ILL LAMP GND
DRIVER INFORMATION CENTER DISPLAY
DRIVER MONITORING CAMERA
DRIVER MONITORING SYSTEM CAMERA LVDS COAXIAL SIGNAL GN COAX
DRIVER MONITORING SYSTEM MODULE
GN COAX
GRY/ORG WIRE
HOT AT ALL TIMES
INSTRUMENT PANEL CLUSTER CONTROL MODULE
LOGIC
PPL
RED/BLU WIRE
RIGHT INSTRUMENT PANEL WIRING HARNESS JUNCTION BLOCK
SINGLE GND
STEERING WHEEL AIR BAG COIL
STEERING WHEEL LED DISPLAY
VIO WIRE
WHT WIRE
WHT/VIO WIRE
YEL/BLU WIRE
YEL/ORG WIRE
Go to component -> Driver monitoring system circuit -> SINGLE GND
