GMC Hummer EV I (2021-2024) rr seat haptic movement mtr ctrl lr seat haptic movement mtr ctrl Wiring diagram
This page shows the only wiring diagram for the component.rr seat haptic movement mtr ctrl lr seat haptic movement mtr ctrl, which is found in the car GMC Hummer EV I (2021-2024). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram rr seat haptic movement mtr ctrl lr seat haptic movement mtr ctrl (1 of 1)
BAT POS VOLT
BLK WIRE
BLK/VIO WIRE
BLU/GRN WIRE
BLU/VIO WIRE
BLU/YEL WIRE
BRN WIRE
CAN BUS (+) 4 SERIAL DATA
COMPUTER DATA LINES SYSTEM
DOWN
DRIVER FRONT SEAT ADJUSTER MEMORY SWITCH
DRIVER FRONT SEAT ADJUSTER SWITCH
DRIVER FRONT SEAT LUMBAR SWITCH
DRIVER SEAT ADJUSTER MEMORY MODULE (UNDER DRIVER SEAT)
DRV SEAT ADJUSTER MEMORY MOD LIN BUS 1 CAN BUS (-) 4 SERIAL DATA
DRV SEAT ADJUSTER MEMORY MOD LIN BUS 2 CAN BUS (-) 4 SERIAL DATA
EXIT
GRN/GRY WIRE
GRN/WHT WIRE
HOT AT ALL TIMES
LEFT FRONT SEAT LANE DEPARTURE WARNING ACTUATOR
LEFT INSTRUMENT PANEL WIRING HARNESS JUNCTION BLOCK
LOGIC
NCA WIRE
RECLINE
RED/BRN WIRE
RED/WHT WIRE
RED/YEL WIRE
RIGHT FRONT SEAT LANE DEPARTURE WARNING ACTUATOR
RR SEAT HAPTIC MOVEMENT MTR CTRL LR SEAT HAPTIC MOVEMENT MTR CTRL
RWD
SEAT MEMORY SW SET SIG
SEAT MEMORY SW SIG 1
SET-
WHT WIRE
YEL/BRN WIRE
Go to component -> Driver"s memory seat circuit (1 of 2) -> RR SEAT HAPTIC MOVEMENT MTR CTRL LR SEAT HAPTIC MOVEMENT MTR CTRL
