GMC Hummer EV I (2021-2024) right rear advanced parking assist alarm sensor Wiring diagram
This page shows the only wiring diagram for the component.right rear advanced parking assist alarm sensor, which is found in the car GMC Hummer EV I (2021-2024). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram right rear advanced parking assist alarm sensor (1 of 1)
BLK/GRY WIRE
BLK/WHT WIRE
BLU WIRE
BLU/BRN WIRE
BLU/GRN WIRE
BLU/YEL WIRE
BODY CONTROL MODULE (UNDER LEFT SIDE OF DASH)
BRN/WHT WIRE
CAN BUS (+) 5 SERIAL DATA
CAN BUS (-) 9 SERIAL DATA
COMPUTER DATA LINES SYSTEM
DISPLAY
GRN WIRE
GRN/GRY WIRE
GRY/GRN WIRE
INSTRUMENT PANEL CLUSTER CONTROL MODULE
LEFT REAR ADVANCED PARKING ASSIST ALARM SENSOR
LEFT REAR MIDDLE PARKING ASSIST ALARM SENSOR
LEFT REAR OUTER PARKING ASSIST ALARM SENSOR
LOGIC
PARALLEL PARKING ASSIST SW
PARKING ASSIST IND
PARKING ASSIST PARALLEL PARKING DISABLE SWITCH SIGNAL
PARKING ASSIST SW
RADIO CONTROL
REAR PARKING ASSIST DISABLE LED SIGNAL
REAR PARKING ASSIST DISABLE SIGNAL
RIGHT REAR ADVANCED PARKING ASSIST ALARM SENSOR
RIGHT REAR MIDDLE PARKING ASSIST ALARM SENSOR
RIGHT REAR OUTER PARKING ASSIST ALARM SENSOR
WHT/GRN WIRE
YEL WIRE
YEL/BLU WIRE
YEL/VIO WIRE
YEL/WHT WIRE
Go to component -> Parking assistant circuit (2 of 2) -> RIGHT REAR ADVANCED PARKING ASSIST ALARM SENSOR
