GMC Hummer EV I (2021-2024) rear sliding window motor Wiring diagram
This page shows the only wiring diagram for the component.rear sliding window motor, which is found in the car GMC Hummer EV I (2021-2024). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram rear sliding window motor (1 of 1)
BATTERY DISTRIBUTION ENGINE COMPARTMENT FUSE BLOCK
BATTERY POSITIVE VOLTAGE
BLK WIRE
BODY CONTROL MODULE
BODY CTRL MODULE LIN BUS 1
BODY CTRL MODULE LIN BUS 2
COMPUTER DATA LINES SYSTEM
ENGINE WIRING HARNESS JUNCTION BLOCK
GRN/BLU WIRE
GRN/BRN WIRE
HOT AT ALL TIMES
ILL
REAR SLIDING WINDOW CLOSE RELAY
REAR SLIDING WINDOW MOTOR
REAR SLIDING WINDOW OPEN RELAY
REAR WINDOW SWITCH
RED/GRY WIRE
RETAINED ACCESSORY POWER CONTROL
RIGHT INSTRUMENT PANEL WIRING HARNESS JUNCTION BLOCK
VIO WIRE
VIO/YEL WIRE
WHT WIRE
YEL WIRE
YEL/VIO WIRE
Go to component -> Sliding rear window circuit -> REAR SLIDING WINDOW MOTOR
