GMC Hummer EV I (2021-2024) rear license plate lamp ctrl Wiring diagram

AUTOSAR CAN BUS (-) 9 SERIAL DATA AUXILIARY PARK LAMP RLY CTRL BATTERY POSITIVE VOLTAGE BLK WIRE BLU/GRN WIRE BLU/WHT WIRE BLU/YEL WIRE BRN/GRN WIRE BRN/GRY WIRE COMPUTER DATA LINES SYSTEM CRUISE/ETC/ TCC BRAKE SIG DRIVER OUTSIDE REAR VIEW MIRROR EXTERIOR FLOOD LAMP DRIVER OUTSIDE REAR- VIEW MIRROR ENGINE WIRING HARNESS JUNCTION BLOCK FRT TURN SIG LAMP FEEDBACK SIG GRN/BRN WIRE GRN/YEL WIRE GRY WIRE GRY/VIO WIRE HOT AT ALL TIMES LEFT REAR LICENSE PLATE LAMP LIGHTING CONTROL MODULE (RIGHT END OF DASH) LOW WASHER FLUID IND CTRL MAJOR ENDGATE AJAR SIG NCA WIRE PARKING LAMP RELAY PASSENGER OUTSIDE REAR VIEW MIRROR PASSENGER OUTSIDE REAR VIEW MIRROR EXTERIOR FLOOD LAMP POWER DISTRIBUTION SYSTEM REAR LICENSE PLATE LAMP CTRL RED/BLU WIRE RED/BRN WIRE RED/GRN WIRE RED/VIO WIRE RED/YEL WIRE RH FRT TURN SIG LP FEEDBACK SIG RIGHT REAR LICENSE PLATE LAMP UPFITTER ACC RLY 1 COIL CTRL UPFITTER ACC RLY 2 COIL CTRL UPFITTER ACC RLY 3 COIL CTRL UPFITTER ACC RLY 4 COIL CTRL UPFITTER ACC RLY 5 COIL CTRL VIO WIRE VIO/BLK WIRE VIO/GRY WIRE WHT/BLU WIRE WHT/BRN WIRE WHT/GRN WIRE WHT/VIO WIRE WHT/YEL WIRE WINDSHIELD WASHER RELAY CTRL WINDSHIELD WIP MTR PARK SW SIG WINDSHIELD WIP MTR RLY COIL CTRL WINDSHIELD WIPER SW HIGH SIG WIPER/WASHER SYSTEM
