GMC Hummer EV I (2021-2024) passenger outside rear view mirror folding actuator Wiring diagram
This page shows the only wiring diagram for the component.passenger outside rear view mirror folding actuator, which is found in the car GMC Hummer EV I (2021-2024). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram passenger outside rear view mirror folding actuator (1 of 1)
BLK WIRE
BLK/GRN WIRE
BLU/GRN WIRE
BLU/GRY WIRE
BLU/YEL WIRE
COAX
COMPUTER DATA LINES SYSTEM
DEFOGGER SYSTEM
DEFOGGER, EXTERIOR LIGHTS, NAVIGATION SYSTEMS
DRIVER FRONT SEAT ADJUSTER MEMORY SWITCH
EXIT
GRN/BLK WIRE
GRN/YEL WIRE
GRY WIRE
LOGIC
NAVIGATION SYSTEM
NCA WIRE
PASSENGER FRONT SIDE DOOR WINDOW SWITCH
PASSENGER OUTSIDE REAR VIEW MIRROR
PASSENGER OUTSIDE REAR VIEW MIRROR ACTUATOR
PASSENGER OUTSIDE REAR VIEW MIRROR EXTERIOR FLOOD LAMP
PASSENGER OUTSIDE REAR VIEW MIRROR FOLDING ACTUATOR
PASSENGER OUTSIDE REAR VIEW MIRROR GLASS
PASSENGER SIDE OBJECT DETECTION INDICATOR
RED/VIO WIRE
RIGHT SIDE VIEW DRIVER INFORMATION CAMERA
SET-
VIO/WHT WIRE
WHT WIRE
WHT/GRN WIRE
YEL/RED WIRE
YEL/VIO WIRE
YEL/WHT WIRE
Go to component -> Memory mirrors circuit (2 of 2) -> PASSENGER OUTSIDE REAR VIEW MIRROR FOLDING ACTUATOR
