GMC Hummer EV I (2021-2024) passenger front seat adjuster actuator Wiring diagram
This page shows the only wiring diagram for the component.passenger front seat adjuster actuator, which is found in the car GMC Hummer EV I (2021-2024). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram passenger front seat adjuster actuator (1 of 1)
BLK WIRE
BLU/BRN WIRE
BLU/WHT WIRE
DOWN
GRN WIRE
GRN/BLU WIRE
GRN/VIO WIRE
GRN/WHT WIRE
HOT AT ALL TIMES
LEFT INSTRUMENT PANEL WIRING HARNESS JUNCTION BLOCK
PASSENGER FRONT SEAT ADJUSTER ACTUATOR
PASSENGER FRONT SEAT ADJUSTER SWITCH
PASSENGER FRONT SEAT RECLINER ACTUATOR
PASSENGER FRONT SEAT TILT ADJUSTER ACTUATOR
PASSENGER FRONT SEAT VERTICAL ADJUSTER ACTUATOR
RECLINE FWD
RECLINE RWD
RED/YEL WIRE
RWD
UP DOWN
YEL/BLU WIRE
YEL/WHT WIRE
Go to component -> Passenger power seat circuit -> PASSENGER FRONT SEAT ADJUSTER ACTUATOR
