GMC Hummer EV I (2021-2024) major endgate low rly ctrl wiring diagram
This page shows the only wiring diagram for the component.major endgate low rly ctrl, which is found in the car GMC Hummer EV I (2021-2024). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
major endgate low rly ctrl wiring diagram (1 of 1)
ACCESSORY POWER RECEPTACLE SWITCH
AUTOSAR CAN BUS (-) 9 SERIAL DATA
BATT +VE VOLTAGE
BLK WIRE
BLU/GRN WIRE
BLU/VIO WIRE
BLU/YEL WIRE
BODY CONTROL MODULE (UNDER LEFT SIDE OF DASH)
BRN WIRE
COMPUTER DATA LINES SYSTEM
DISPLAY
ENDGATE RELEASE SWITCH
ENGINE WIRING HARNESS JUNCTION BLOCK
GRN WIRE
GROUND
GROUND PICKUP BOX ENDGATE LATCH RELAY
GRY WIRE
HIGH MOUNT STOP LAMP
HOT AT ALL TIMES
INSTRUMENT PANEL CLUSTER CONTROL MODULE
LEFT INSTRUMENT PANEL WIRING HARNESS JUNCTION BLOCK
LEFT PICKUP BOX ENDGATE LATCH
LIGHTING CONTROL MODULE (RIGHT END OF DASH)
LOGIC
MAJOR ENDGATE AJAR SIG
MAJOR ENDGATE HI RLY CTRL
MAJOR ENDGATE LOW RLY CTRL
MAJOR ENDGATE REL SWITCH SIGNAL EXTERIOR
MAJOR ENDGATE REL SWITCH SIGNAL INTERIOR
NCA WIRE
PICKUP BOX ENDGATE LATCH HANDLE
RED/GRN WIRE
RED/GRY WIRE
RIGHT INSTRUMENT PANEL WIRING HARNESS JUNCTION BLOCK
RIGHT PICKUP BOX ENDGATE LATCH
SUPPLY VOLTAGE PICKUP BOX ENDGATE LATCH RELAY
WHT/GRN WIRE
YEL/BLK WIRE
Go to component -> Endgate circuit, primary -> MAJOR ENDGATE LOW RLY CTRL
