GMC Hummer EV I (2021-2024) lt headlamp hi beam ctrl Wiring diagram
This page shows the only wiring diagram for the component.lt headlamp hi beam ctrl, which is found in the car GMC Hummer EV I (2021-2024). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram lt headlamp hi beam ctrl (1 of 1)
AIR CONDITIONING SYSTEM
AUTOSAR CAN BUS (+) 2 SERIAL DATA
BLK WIRE
BLK/WHT WIRE
BLK/YEL WIRE
BLU/BRN WIRE
BLU/GRN WIRE
COMPUTER DATA LINES SYSTEM
DRL
GRN/YEL WIRE
GRY/BLU WIRE
HEADLAMP COOLING FAN
HIGH BEAM
LEFT FRONT DRL CONTROL
LIGHTING CONTROL MODULE
LOGIC
LOW BEAM
LT HEADLAMP HI BEAM CTRL
LT HEADLAMP LO BEAM CTRL
PARK BRAKE SWITCH
PARKING BRAKE CONTROL SWITCH
RED/BRN WIRE
RED/YEL WIRE
RIGHT END OF DASH)
RIGHT FRONT DRL CONTROL
RIGHT FRONT HEADLAMP
RIGHT LOWER HEADLAMP LED DRIVER MODULE
RIGHT UPPER HEADLAMP LED DRIVER MODULE
RT HEADLAMP HI BEAM CTRL
RT HEADLAMP LO BEAM CTRL
SUNLOAD TEMPERATURE, HEADLAMP AUTOMATIC CONTROL AMBIENT LIGHT SENSOR
WHT WIRE
WHT/BLU WIRE
WHT/GRN WIRE
YEL WIRE
Go to component -> Headlights circuit (3 of 3) -> LT HEADLAMP HI BEAM CTRL
