GMC Hummer EV I (2021-2024) lf frt side impact sens sig Wiring diagram
This page shows the only wiring diagram for the component.lf frt side impact sens sig, which is found in the car GMC Hummer EV I (2021-2024). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram lf frt side impact sens sig (1 of 1)
BAT CUT-OFF MODULE LOW CTRL
BAT CUTOFF RESTRAINT 2 HIGH CTRL
BAT CUTOFF RESTRAINT 2 LOW CTRL
BLK/ORG WIRE
BLU/ORG WIRE
BRN/ORG WIRE
DRIVER FRONT SEAT OUTBOARD SEAT BACK AIR BAG
DRIVER SEAT BACK AIR BAG HIGH CTRL
DRIVER SEAT BACK AIR BAG LOW CTRL
DRIVER SEAT BELT SENS SIG
DRIVER SEAT BELT SW LOW REF
DRIVER SEAT BELT SWITCH DRIVER FRONT SEAT BELT BUCKLE
ENGINE CONTROLS SYSTEM
GRY/ORG WIRE
HOT AT ALL TIMES
LEFT FRONT DOOR AIR BAG SIDE IMPACT SENSOR
LEFT INSTRUMENT PANEL WIRING HARNESS JUNCTION BLOCK
LEFT ROCKER PANEL EXTENSION AIR BAG SIDE IMPACT REAR SENSOR
LF FRT SIDE IMPACT SENS LOW REF
LF FRT SIDE IMPACT SENS SIG
LF RR SIDE IMPACT SENS LOW REF
LF RR SIDE IMPACT SENS SIG
NCA WIRE
ORG/BLU WIRE
ORG/BRN WIRE
ORG/GRN WIRE
ORG/GRY WIRE
ORG/VIO WIRE
ORG/WHT WIRE
ORG/YEL WIRE
PASS SEAT BACK AIR BAG HIGH CTRL
PASS SEAT BACK AIR BAG LOW CTRL
PASS SEAT BELT SW SIG
PASSENGER FRONT SEAT OUTBOARD SEAT BACK AIR BAG
PYROTECHNIC BAT CUT-OFF ACU
RED/GRN WIRE
RESTRAINTS CONTROL MODULE (UNDER FLOOR CONSOLE)
RH FRT SIDE IMPACT SENS LOW REF
RH FRT SIDE IMPACT SES SIG
RH RR SIDE IMPACT SENS LOW REF
RH RR SIDE IMPACT SENS SIG
Go to component -> Supplemental restraints circuit (1 of 4) -> LF FRT SIDE IMPACT SENS SIG
