GMC Hummer EV I (2021-2024) lf frt imp discriminating sens low ref Wiring diagram
This page shows the only wiring diagram for the component.lf frt imp discriminating sens low ref, which is found in the car GMC Hummer EV I (2021-2024). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram lf frt imp discriminating sens low ref (1 of 1)
BATTERY POSITIVE VOLTAGE
BLK/ORG WIRE
BLK/WHT WIRE
BLU WIRE
BLU/GRN WIRE
BRN/ORG WIRE
CAN-BUS
COMPUTER DATA LINES SYSTEM
DRIVER FRONT SEAT BELT ANCHOR PLATE TENSIONER
DRIVER FRONT SEAT BELT RETRACTOR
DRIVER SEAT BELT ANCHOR PRETENSIONER HIGH CTRL
DRIVER SEAT BELT ANCHOR PRETENSIONER LOW CTRL
DRIVER SEAT BELT RETRACTOR PRETENSIONER HIGH CTRL
DRIVER SEAT BELT RETRACTOR PRETENSIONER LOW CTRL
GRN WIRE
GRY/ORG WIRE
LEFT AIR BAG FRONT END DISCRIMINATING SENSOR
LF FRT IMP DISCRIMINATING SENS LOW REF
LF FRT IMP DISCRIMINATING SENS SIG
ORG/BRN WIRE
ORG/GRN WIRE
ORG/VIO WIRE
ORG/WHT WIRE
ORG/YEL WIRE
PASS AIR BAG OFF INDICATOR CTRL PASS INSTRUMENT PANEL AIR BAG STAGE 2 LOW CTRL
PASS AIR BAG ON INDICATOR CTRL
PASS INSTRUMENT PANEL AIR BAG STAGE 1 HIGH CTRL
PASS INSTRUMENT PANEL AIR BAG STAGE 1 LOW CTRL
PASS INSTRUMENT PANEL AIR BAG STAGE 2 HIGH CTRL
PASS SEAT BELT ANCHOR PRETENSIONER HIGH CTRL
PASS SEAT BELT ANCHOR PRETENSIONER LOW CTRL
PASS SEAT BELT INDICATOR CTRL
PASS SEAT BELT RETRACTOR PRETENSIONER HIGH CTRL
PASS SEAT BELT RETRACTOR PRETENSIONER LOW CTRL
PASSENGER FRONT SEAT BELT ANCHOR PLATE TENSIONER
PASSENGER FRONT SEAT BELT RETRACTOR
RED/GRN WIRE
RESTRAINTS CONTROL MODULE (UNDER FLOOR CONSOLE)
RH FRT IMP DISCRIMINATING SENS LOW REF
RH FRT IMP DISCRIMINATING SENS SIG
RIGHT AIR BAG FRONT END DISCRIMINATING SENSOR
RUN/CRANK IGNITION 1 VOLTAGE
SIG GND
STEERING WHEEL AIR BAG STAGE 1 HIGH CTRL
STEERING WHEEL AIR BAG STAGE 1 LOW CONTROL
STEERING WHEEL AIR BAG STAGE 2 HIGH CTRL
STEERING WHEEL AIR BAG STAGE 2 LOW CTRL
VIO/GRY WIRE
VIO/ORG WIRE
VIO/WHT WIRE
WHT/GRN WIRE
WHT/ORG WIRE
YEL/ORG WIRE
Go to component -> Supplemental restraints circuit (4 of 4) -> LF FRT IMP DISCRIMINATING SENS LOW REF
