GMC Hummer EV I (2021-2024) left rear side short range radar sensor Wiring diagram
This page shows the only wiring diagram for the component.left rear side short range radar sensor, which is found in the car GMC Hummer EV I (2021-2024). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram left rear side short range radar sensor (1 of 1)
AUTOSAR CAN BUS (+) 5 SERIAL DATA
BLK/WHT WIRE
BLU/GRN WIRE
BLU/GRY WIRE
BLU/YEL WIRE
COMPUTER DATA LINES SYSTEM
DISPLAY
ENGINE WIRING HARNESS JUNCTION BLOCK
HOT AT ALL TIMES
INSTRUMENT PANEL CLUSTER CONTROL MODULE
LEFT FRONT SHORT RANGE RADAR SENSOR
LEFT REAR SIDE SHORT RANGE RADAR SENSOR
LOGIC
LONG RANGE FORWARD RANGE RADAR SENSOR
POWER DISTRIBUTION SYSTEM
RED/BLU WIRE
RED/WHT WIRE
RIGHT FRONT SHORT RANGE RADAR SENSOR
RIGHT REAR SIDE SHORT RANGE RADAR SENSOR
WHT/GRY WIRE
WHT/RED WIRE
Go to component -> Collision avoidance circuit (2 of 2) -> LEFT REAR SIDE SHORT RANGE RADAR SENSOR
