GMC Hummer EV I (2021-2024) left rear side door courtesy lamp Wiring diagram
This page shows the only wiring diagram for the component.left rear side door courtesy lamp, which is found in the car GMC Hummer EV I (2021-2024). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram left rear side door courtesy lamp (1 of 1)
BLK WIRE
BRN/VIO WIRE
COMPUTER DATA LINES SYSTEM
DRIVER FRONT SIDE DOOR COURTESY LAMP
FRONT FLOOR CONSOLE COMPARTMENT LAMP
GRN/VIO WIRE
GRN/YEL WIRE
GRY WIRE
GRY/BLU WIRE
LEFT REAR SIDE DOOR COURTESY LAMP
LIN BUS 3
LOGIC
PASSENGER FRONT SIDE DOOR COURTESY LAMP
PASSENGER FRONT SIDE DOOR LATCH
PASSENGER FRONT SIDE DOOR WINDOW CONTROL SWITCH
PASSENGER FRONT SIDE DOOR WINDOW REGULATOR MOTOR
RF DR AJAR
RIGHT FRONT SIDE DOOR INSIDE HANDLE ILLUMINATION LAMP
RIGHT FRONT SIDE DOOR MAP POCKET ILLUMINATION LAMP
RIGHT REAR SIDE DOOR COURTESY LAMP
SW SIG
VIO WIRE
WHT/BLK WIRE
WHT/BRN WIRE
Go to component -> Courtesy lamps circuit (3 of 5) -> LEFT REAR SIDE DOOR COURTESY LAMP
