GMC Hummer EV I (2021-2024) left front duct air temperature sensor Wiring diagram
This page shows the only wiring diagram for the component.left front duct air temperature sensor, which is found in the car GMC Hummer EV I (2021-2024). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram left front duct air temperature sensor (1 of 1)
AIR CONDITIONING EVAPORATOR AIR TEMPERATURE SENSOR
AIR TEMP SENS SIG
AUTOSAR CAN BUS (-) 9 SERIAL DATA
BATT POS VOLT
BLK WIRE
BLK/WHT WIRE
BLK/YEL WIRE
BLOWER MOTOR (BOTTOM OF HVAC UNIT)
BLOWER SPD FEEDBACK SIG
BLU/GRN WIRE
BLU/GRY WIRE
BLU/VIO WIRE
BLU/WHT WIRE
BLU/YEL WIRE
BLWR MTR SPD CTRL
BODY CONTROL MODULE (UNDER LEFT SIDE OF DASH)
BRN WIRE
BRN/YEL WIRE
COMPUTER DATA LINES SYSTEM
DISPLAY
DRV SOLAR SENS SIG
GRN/BLU WIRE
GROUND
GRY WIRE
GRY/BRN WIRE
GRY/GRN WIRE
HEADLIGHTS SYSTEM
HVAC REM ENABLE SIG
HVAC SYSTEM ENABLE SIG
ILL
LEFT FRONT DUCT AIR TEMPERATURE SENSOR
LOGIC
LVDS
LVDS GY
RADIO
RADIO CONTROL
RED/GRY WIRE
RED/WHT WIRE
RIGHT FRONT DUCT AIR TEMPERATURE SENSOR
SECURITY IND CTRL
SENS LO REF
SUNLOAD TEMPERATURE, HEADLAMP AUTOMATIC CONTROL AMBIENT LIGHT SENSOR
TEMP SENS SIG
WHT/BLU WIRE
WHT/BRN WIRE
WHT/GRN WIRE
WHT/YEL WIRE
Go to component -> Air conditioning circuit (1 of 6) -> LEFT FRONT DUCT AIR TEMPERATURE SENSOR
