GMC Hummer EV I (2021-2024) hybrid/electric vehicle battery control wiring junction block Wiring diagrams
This page contains all the electrical diagrams for the component. hybrid/electric vehicle battery control wiring junction block, in which he is found in the car GMC Hummer EV I (2021-2024). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram hybrid/electric vehicle battery control wiring junction block (1 of 4)
AIR CONDITIONING REFRIGERANT TEMPERATURE SENSOR 8
BLK WIRE
BLK/BLU WIRE
BLK/BRN WIRE
BLK/VIO WIRE
BLK/WHT WIRE
BLK/YEL WIRE
BLU/BLK WIRE
BLU/GRN WIRE
BRN/BLK WIRE
COMPUTER DATA LINES SYSTEM
COOLANT ELECTRIC
GRN/GRY WIRE
GRN/VIO WIRE
GROUND
GRY/VIO WIRE
GRY/YEL WIRE
HEATER
HEATER CTRL
HOT AT ALL TIMES
HYBRID/ ELECTRIC VEHICLE BATTERY PACK
HYBRID/ PROPULSION SYSTEM COOLANT TEMPERATURE SENSOR 1
HYBRID/ PROPULSION SYSTEM COOLANT TEMPERATURE SENSOR 2
HYBRID/ PROPULSION SYSTEM COOLANT TEMPERATURE SENSOR 3
HYBRID/ PROPULSION SYSTEM COOLANT TEMPERATURE SENSOR 4
HYBRID/ELECTRIC VEHICLE BATTERY CONTROL WIRING JUNCTION BLOCK
HYBRID/ELECTRIC VEHICLE BATTERY COOLANT PUMP
HYBRID/ELECTRIC VEHICLE COOLANT HEATER
LEFT INSTRUMENT PANEL WIRING HARNESS JUNCTION BLOCK
LIN BUS 3
LOGIC
ORG/ WIRE
ORG/BLK WIRE
RED/BLU WIRE
RED/BRN WIRE
RED/WHT WIRE
WHT/GRN WIRE
WHT/YEL WIRE
YEL/BRN WIRE
Go to component -> Air conditioning circuit (5 of 6) -> HYBRID/ELECTRIC VEHICLE BATTERY CONTROL WIRING JUNCTION BLOCK
Wiring diagram hybrid/electric vehicle battery control wiring junction block (2 of 4)
AMBIENT AIR TEMPERATURE SENSOR
AUTOSAR CAN BUS (+) 2 SERIAL DATA
BATT POS VOLT
BATTERY ENERGY CONTROL MODULE 1
BLK WIRE
BLK/BLU WIRE
BLK/GRN WIRE
BLK/VIO WIRE
BLK/WHT WIRE
BLK/YEL WIRE
BLU/GRN WIRE
BLU/GRY WIRE
BLU/YEL WIRE
BRN/BLK WIRE
COMPUTER DATA LINES SYSTEM
COOLANT ELECTRIC
COOLANT ELECTRIC HTR CTRL
COOLING FAN MOTOR (REAR OF RADIATOR)
GRN/BRN WIRE
GRN/GRY WIRE
GRN/VIO WIRE
GROUND
GRY/VIO WIRE
HEATER
HEATER CTRL
HYBRID/ ELECTRIC VEHICLE BATTERY PACK
HYBRID/ELECTRIC VEHICLE BATTERY CONTROL WIRING JUNCTION BLOCK
HYBRID/ELECTRIC VEHICLE BATTERY COOLANT PUMP
HYBRID/ELECTRIC VEHICLE COOLANT HEATER
HYBRID/ELECTRIC VEHICLE ELECTRONICS COOLANT PUMP
HYBRID/ELECTRIC VEHICLE PROPULSION SYSTEM COOLANT CONTROL VALVE 1
LIN BUS 3
LOGIC
ORG/ WIRE
ORG/BLK WIRE
RED/BLU WIRE
RED/GRY WIRE
RED/VIO WIRE
RED/WHT WIRE
SENS LOW REF (2)
SIGNAL GROUND
TEMP SENS A SIG
TEMP SENS B LOW REF
TEMP SENS B SIG
TEMP SENS C SIG
TEMP SENS D LOW REF
TEMP SENS D SIG
TEMP SENS E LOW REF
TEMP SENS E SIG
TEMP SENS LOW REF
TEMP SENS SIG
WHT WIRE
WHT/YEL WIRE
YEL/BRN WIRE
Go to component -> Cooling fan circuit (1 of 2) -> HYBRID/ELECTRIC VEHICLE BATTERY CONTROL WIRING JUNCTION BLOCK
Wiring diagram hybrid/electric vehicle battery control wiring junction block (3 of 4)
AIR CONDITIONING COMPRESSOR CONTROL MODULE
AIR CONDITIONING W/ MOTOR COMPRESSOR
BRN/GRN WIRE
FROM HYBRID/ ELECTRIC VEHICLE BATTERY CUT-OFF ACTUATOR 2 (DIAGRAM 9 OF 11)
FROM HYBRID/ELECTRIC VEHICLE BATTERY CUT-OFF ACTUATOR (DIAGRAM 9 OF 11)
FUSE FLL
FUSE FLRI
FUSE FUL
FUSE FURI
FUSE FURO
GRN/BLU WIRE
GRN/WHT WIRE
GRY WIRE
GRY/BLU WIRE
HYBRID/ELECTRIC VEHICLE BATTERY CONTACTOR- DC POSITIVE RELAY
HYBRID/ELECTRIC VEHICLE BATTERY CONTACTOR- POSITIVE 2 RELAY
HYBRID/ELECTRIC VEHICLE BATTERY CONTACTOR- POSITIVE RELAY
HYBRID/ELECTRIC VEHICLE BATTERY CONTACTOR- PRECHARGE 2 RELAY
HYBRID/ELECTRIC VEHICLE BATTERY CONTACTOR- PRECHARGE RELAY
HYBRID/ELECTRIC VEHICLE BATTERY CONTACTOR- SERIES POSITIVE RELAY
HYBRID/ELECTRIC VEHICLE BATTERY CONTROL WIRING JUNCTION BLOCK
HYBRID/ELECTRIC VEHICLE BATTERY DISCONNECT RELAY
HYBRID/ELECTRIC VEHICLE BATTERY PACK SECTIONS 1
HYBRID/ELECTRIC VEHICLE BATTERY PACK SECTIONS 2
HYBRID/ELECTRIC VEHICLE BATTERY PRECHARGE RESISTOR
HYBRID/ELECTRIC VEHICLE BATTERY PRECHARGE RESISTOR 2 RELAY
HYBRID/ELECTRIC VEHICLE COOLANT HEATER
LOGIC
N/A
N/A N/A
ORG/ WIRE
RED/VIO WIRE
TO FUSE FLRO (DIAGRAM 9 OF 11)
VIO/GRN WIRE
WHT WIRE
YEL/VIO WIRE
Go to component -> Wiring diagram engine performance electric (10 of 11) -> HYBRID/ELECTRIC VEHICLE BATTERY CONTROL WIRING JUNCTION BLOCK
Wiring diagram hybrid/electric vehicle battery control wiring junction block (4 of 4)
AIR CONDITIONING SYSTEM
BLU/ORG WIRE
BRN/GRN WIRE
FUSE FLRO
GRN/BLU WIRE
GRY WIRE
GRY/BLK WIRE
GRY/BLU WIRE
GRY/BRN WIRE
HYBRID/ELECTRIC VEHICLE BATTERY CONTACTOR- DC NEGATIVE RELAY
HYBRID/ELECTRIC VEHICLE BATTERY CONTACTOR- NEGATIVE 2 RELAY
HYBRID/ELECTRIC VEHICLE BATTERY CONTACTOR- NEGATIVE RELAY
HYBRID/ELECTRIC VEHICLE BATTERY CONTACTOR- SERIES NEGATIVE RELAY
HYBRID/ELECTRIC VEHICLE BATTERY CONTROL WIRING JUNCTION BLOCK
HYBRID/ELECTRIC VEHICLE BATTERY CURRENT SENSOR 1
HYBRID/ELECTRIC VEHICLE BATTERY CURRENT SENSOR 2
HYBRID/ELECTRIC VEHICLE BATTERY CUT-OFF ACTUATOR
HYBRID/ELECTRIC VEHICLE BATTERY CUT-OFF ACTUATOR 2
HYBRID/ELECTRIC VEHICLE BATTERY DISCONNECT RELAY
LOGIC
N/A
ORG/ WIRE
ORG/BLK WIRE
ORG/BRN WIRE
ORG/YEL WIRE
RED/VIO WIRE
SUPPLEMENTAL RESTRAINTS SYSTEM
TO HYBRID/ELECTRIC VEHICLE BATTERY PACK SECTIONS 1 (DIAGRAM 10 OF 11)
TO HYBRID/ELECTRIC VEHICLE BATTERY PACK SECTIONS 2 (DIAGRAM 10 OF 11)
VIO/BLU WIRE
VIO/GRN WIRE
VIO/GRY WIRE
YEL/VIO WIRE
Go to component -> Wiring diagram engine performance electric (9 of 11) -> HYBRID/ELECTRIC VEHICLE BATTERY CONTROL WIRING JUNCTION BLOCK
