GMC Hummer EV I (2021-2024) high frequency antenna Wiring diagram
This page shows the only wiring diagram for the component.high frequency antenna, which is found in the car GMC Hummer EV I (2021-2024). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram high frequency antenna (1 of 1)
ACCESSORY TIME DELAY CUTOFF RELAY 1
AIR CONDITIONING COOLER ELECTRONIC EXPANSION VALVE
AUTOMATIC TRANSMISSION AUXILIARY FLUID PUMP 1
BATTERY ENERGY CONTROL MODULE 2
BLK WIRE
BLK/WHT WIRE
BLOWER MOTOR
CONDITIONING COMPRESSOR CONTROL MODULE
CONDITIONING W/ MOTOR COMPRESSOR
FRONT FLOOR CONSOLE FLOOD LAMP
FRONT IDENTIFICATION LAMP
GARAGE DOOR OPENER TRANSMITTER
HIGH FREQUENCY ANTENNA
HYBRID/ ELECTRIC VEHICLE BATTERY COOLANT PUMP
HYBRID/ ELECTRIC VEHICLE COOLANT HEATER
HYBRID/ ELECTRIC VEHICLE ELECTRONICS COOLANT PUMP
IGNITION MAIN RELAY
INTERIOR LAMP SWITCH
LEFT FRONT CENTER READING LAMP
LEFT PROGRAMMABLE TEMPERATURE VALVE ACTUATOR
LEFT SUNSHADE
LEFT SUNSHADE MIRROR LAMP
NCA WIRE
PROGRAMMABLE AIR INLET VALVE ACTUATOR
PROGRAMMABLE MODE VALVE ACTUATOR
RADIO
RADIO CONTROL
REAR BLOWER MOTOR CONTROL MODULE
REAR POWER STEERING CONTROL MODULE
REAR PROGRAMMABLE TEMPERATURE VALVE ACTUATOR
REAR WINDOW SWITCH
REMOTE FUNCTION ACTUATOR MODULE
RIGHT FRONT CENTER READING LAMP
RIGHT FRONT FLOOR COURTESY LAMP
RIGHT INSTRUMENT PANEL WIRING HARNESS JUNCTION BLOCK
RIGHT PROGRAMMABLE TEMPERATURE VALVE ACTUATOR
RIGHT SUNSHADE RIGHT SUNSHADE MIRROR LAMP
SERIAL DATA GATEWAY MODULE
Go to component -> Ground distribution circuit (3 of 8) -> HIGH FREQUENCY ANTENNA
