GMC Hummer EV I (2021-2024) driver heated switch Wiring diagram
This page shows the only wiring diagram for the component.driver heated switch, which is found in the car GMC Hummer EV I (2021-2024). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram driver heated switch (1 of 1)
AUTO SWITCH
BLK WIRE
BLK/VIO WIRE
BLK/WHT WIRE
BLU/BLK WIRE
BLU/RED WIRE
BLU/VIO WIRE
BLU/WHT WIRE
BLU/YEL WIRE
BRN/BLK WIRE
COMPUTER DATA LINES SYSTEM
DISPLAY
DRIVER HEATED SWITCH
GRN/BLK WIRE
GRN/BRN WIRE
GRY/BRN WIRE
HEATER AIR CONDITIONING CONDENSER REFRIGERANT FLOW VALVE
HEATER, AIR CONDITIONING AUXILIARY CONTROL
HIGH HEAT IND
HYBRID/ELECTRIC VEHICLE PROPULSION SYSTEM COOLANT CONTROL VALVE 1
LOGIC
LOW HEAT IND
MEDIUM HEAT IND
MODE SWITCH
PASSENGER HEATED SWITCH
REAR BLOWER MOTOR
REAR BLOWER MOTOR CONTROL MODULE
REAR PROGRAMMABLE MODE VALVE ACTUATOR
RED/BLU WIRE
RED/BRN WIRE
RED/GRY WIRE
RED/WHT WIRE
RED/YEL WIRE
TEMPERATURE CONTROL SWITCH
VENTILATING FAN SWITCH
YEL/WHT WIRE
Go to component -> Air conditioning circuit (3 of 6) -> DRIVER HEATED SWITCH
