GMC Hummer EV I (2021-2024) drive unit sump oil temp sensor 2 low reference Wiring diagram
This page shows the only wiring diagram for the component.drive unit sump oil temp sensor 2 low reference, which is found in the car GMC Hummer EV I (2021-2024). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram drive unit sump oil temp sensor 2 low reference (1 of 1)
AUTOMATIC TRANSMISSION AUXILIARY FLUID PUMP 1
AUTOMATIC TRANSMISSION AUXILIARY FLUID PUMP 2
AUTOSAR CAN BUS (-) 2 SER DATA
BLK WIRE
BLK/GRY WIRE
BLK/WHT WIRE
BLU WIRE
BLU/YEL WIRE
BRN WIRE
BRN/YEL WIRE
COMPUTER DATA LINES SYSTEM
DRIVE MOTOR CONTROL MODULE 1
DRIVE MOTOR CONTROL MODULE 2
DRIVE UNIT SUMP OIL TEMP SENSOR 2 LOW REFERENCE
DRIVE UNIT SUMP OIL TEMP SENSOR 2 SIGNAL
ENGINE WIRING HARNESS JUNCTION BLOCK
FRONT DIFFERENTIAL LOCKING ACTUATOR
FRONT DRIVE UNIT FLUID TEMPERATURE SENSOR
FRONT ELECTRIC DRIVE TRANSMISSION MODULE
GRN/BLU WIRE
HIGH SPD SER DATA (+) (1)
HIGH SPD SER DATA (-) 3
HOT AT ALL TIMES
LOGIC
MANUAL SHIFT SHAFT MOTOR
NCA WIRE
PRNDL A SIGNAL
PRNDL B SIGNAL
PRNDL P SIGNAL
REAR DRIVE UNIT FLUID TEMPERATURE SENSOR
REAR ELECTRIC DRIVE TRANSMISSION MODULE
RED/GRN WIRE
RED/VIO WIRE
RED/WHT WIRE
TRANSMISSION OIL PUMP 2 CONTROL
TRANSMISSION OIL PUMP 2 DIAGNOSTIC FEEDBACK SIGNAL
TRANSMISSION OIL PUMP CONTROL
TRANSMISSION OIL PUMP DIAGNOSTIC FEEDBACK SIGNAL
TRANSMISSION PARK POSITION SENSOR
VIO/BLK WIRE
VIO/RED WIRE
VIO/WHT WIRE
VOLTAGE SUPPLY A
WHT WIRE
WHT/BLK WIRE
WHT/GRY WIRE
YEL/GRY WIRE
Go to component -> Transmission circuit (1 of 2) -> DRIVE UNIT SUMP OIL TEMP SENSOR 2 LOW REFERENCE
