GMC Hummer EV I (2021-2024) cinch latch Wiring diagram
This page shows the only wiring diagram for the component.cinch latch, which is found in the car GMC Hummer EV I (2021-2024). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram cinch latch (1 of 1)
ACCESSORY POWER RECEPTACLE SWITCH
BACKUP LAMP
BACKUP LAMPS CIRCUIT
BLK WIRE
BLU/GRN WIRE
BLU/VIO WIRE
BLU/WHT WIRE
BLU/YEL WIRE
BRN/BLU WIRE
BRN/GRN WIRE
BRN/GRY WIRE
BRN/YEL WIRE
CINCH LATCH
ENABLE
ENGINE WIRING HARNESS JUNCTION BLOCK
FRONT CLOSURE
GRN/WHT WIRE
GRY/ORG WIRE
GRY/RED WIRE
HOT AT ALL TIMES
LEFT LATCH PICKUP BOX ENDGATE
LEFT REAR BODY STRUCTURE STOP LAMP
LEFT TURN LAMPS
LOGIC
MOTOR POWER
PARK LIGHTS
POWERTRAIN COMPARTMENT COVER MODULE
RED/BLU WIRE
RED/GRY WIRE
RIGHT REAR BODY STRUCTURE STOP LAMP
RIGHT TURN LAMPS)
STOP LAMP
WHT/BLK WIRE
WHT/BLU WIRE
WHT/VIO WIRE
YEL/GRN WIRE
Go to component -> Exterior lamps circuit (4 of 5) -> CINCH LATCH
