GMC Hummer EV I (2021-2024) cargo area auxiliary rear view camera Wiring diagram
This page shows the only wiring diagram for the component.cargo area auxiliary rear view camera, which is found in the car GMC Hummer EV I (2021-2024). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram cargo area auxiliary rear view camera (1 of 1)
1-BG REAR VIEW CAMERA LVDS COAXIAL SIGNAL
1-BK COAX
1-BN TRAILER REAR VISION CAMERA LVDS COAXIAL SIGNAL
1-CU FRONT VIEW CAMERA LVDS COAXIAL SIGNAL
1-GN CARGO BED REAR VISION CAMERA LVDS COAXIAL SIGNAL
2-BG RH SIDE VISION CAMERA COAXIAL SIGNAL
2-BK
2-BN LEFT SIDE VIEW CAMERA LVDS COAXIAL SIGNAL
2-CU RIGHT SIDE VIEW CAMERA LVDS COAXIAL SIGNAL
2-GN UNDERBODY CAMERA LVDS COAXIAL SIGNAL
BATTERY POSITIVE VOLTAGE
BK COAX
BK LVDS
BLK/WHT WIRE
BLU WIRE
CAN BUS (-) 1 SERIAL DATA
CARGO AREA AUXILIARY REAR VIEW CAMERA
COAX
COMPUTER DATA LINES SYSTEM
DISPLAY
DRIVER OUTSIDE REAR- VIEW MIRROR
FRONT VIEW UNDERBODY CAMERA
GRILLE FRONT VIEW DRIVER INFORMATION CAMERA
HOT AT ALL TIMES
LEFT INSTRUMENT PANEL WIRING HARNESS JUNCTION BLOCK
LEFT SIDE VIEW DRIVER INFORMATION CAMERA
LOGIC
LVDS
PASSENGER OUTSIDE REAR VIEW MIRROR
RADIO
RADIO CONTROL
RD VIDEO PROCESSING MODULE LVDS COAXIAL SIGNAL
REAR VIEW CAMERA DRIVER INFORMATION
REAR VIEW UNDERBODY CAMERA
RED/VIO WIRE
RIGHT SIDE VIEW DRIVER INFORMATION CAMERA
SIGNAL GROUND
TOW VEHICLE ELECTRICAL RECEPTACLE
VIDEO PROCESSING MODULE (UNDER RIGHT SIDE OF DASH)
WH COAX
WHT WIRE
Go to component -> All around vision camera circuit -> CARGO AREA AUXILIARY REAR VIEW CAMERA
