GMC Hummer EV I (2021-2024) body control module lin bus 6 Wiring diagram
This page shows the only wiring diagram for the component.body control module lin bus 6, which is found in the car GMC Hummer EV I (2021-2024). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram body control module lin bus 6 (1 of 1)
AMBIENT LIGHT SNS SIG
AUTO HIGH BEAM ASSIST SWITCH SIGNAL
AUTO HIGH BEAM SWITCH
AUTO OFF
BLK WIRE
BLK/WHT WIRE
BLK/YEL WIRE
BODY CONTROL MODULE (UNDER LEFT SIDE OF DASH)
BODY CONTROL MODULE LIN BUS 6
COMPUTER DATA LINES SYSTEM
DIMMER SWITCH
DRIVER INFORMATION CENTER DISPLAY
DRL IND
ENGINE WIRING HARNESS JUNCTION BLOCK
FLASH TO PASS SWITCH
FOG LAMP IND
FRONT FOG LAMP SWITCH
GRN/BLK WIRE
GRN/BRN WIRE
GRN/GRY WIRE
GRN/VIO WIRE
GRY/BRN WIRE
HEAD
HEADLAMP SWITCH FLASH SIGNAL
HEADLAMP SWITCH OFF SIGNAL
HEADLAMP SWITCH ON SIGNAL
HIGH BEAM ASSIST SWITCH
HIGH BEAM LAMP IND
HIGH BEAM SELECT SWITCH HIGH BEAM SIGNAL
HOT AT ALL TIMES
INSTRUMENT PANEL CLUSTER CONTROL MODULE
LIN BUS 1
LOGIC
LOW REF
PARK
REAR FOG LAMP SWITCH
RED/BRN WIRE
RED/GRY WIRE
RED/VIO WIRE
RED/WHT WIRE
RED/YEL WIRE
SENSOR LOW REFERENCE
TURN SIGNAL SWITCH
WHT WIRE
WHT/BLU WIRE
WHT/VIO WIRE
YEL/BRN WIRE
Go to component -> Headlights circuit (1 of 3) -> BODY CONTROL MODULE LIN BUS 6
