GMC Hummer EV I (2021-2024) active noise cancellation microphone 1 signal Wiring diagrams
This page contains all the electrical diagrams for the component. active noise cancellation microphone 1 signal, in which he is found in the car GMC Hummer EV I (2021-2024). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram active noise cancellation microphone 1 signal (1 of 2)
ACTIVE NOISE CANCELLATION MICROPHONE 1 FEEDBACK SIGNAL
ACTIVE NOISE CANCELLATION MICROPHONE 1 SIGNAL
AUDIO AMPLIFIER
AUTOSAR CAN BUS (+) 5 SERIAL DATA
BLK/WHT WIRE
BLU WIRE
BLU/BLK WIRE
BLU/BRN WIRE
BLU/VIO WIRE
BLU/WHT WIRE
BLU/YEL WIRE
BRN/BLK WIRE
BRN/BLU WIRE
COMPUTER DATA LINES SYSTEM
ETHERNET BUS 6 (-)
FRONT CENTER SPEAKER (-) CTRL
GRN WIRE
GRN/BLK WIRE
GRN/BRN WIRE
GRN/RED WIRE
GRN/VIO WIRE
GRY/BLK WIRE
HOT AT ALL TIMES
LEFT FRONT RADIO SPEAKER INSTRUMENT PANEL
LEFT FRONT SPEAKER 1 (+) CTRL
LEFT FRONT SPEAKER CTRL (+) 1
LEFT INSTRUMENT PANEL WIRING HARNESS JUNCTION BLOCK
NCA WIRE
RADIO FRONT CENTER SPEAKER
RADIO VOLUME COMPENSATOR INTERIOR NOISE MICROPHONE
REAR/LEFT REAR SURROUND SPEAKER (-) CTRL
RED/GRN WIRE
RIGHT FRONT MIDRANGE SPEAKER (+) CTRL
RIGHT FRONT RADIO SIDE DOOR SPEAKER
RIGHT FRONT RADIO SPEAKER INSTRUMENT PANEL
RIGHT FRONT RADIO WINDSHIELD SIDE GARNISH MOLDING SPEAKER
RIGHT FRONT SPEAKER 1 (+) CTRL
RIGHT FRONT SPEAKER CTRL (+) 1
RIGHT SUBWOOFER (-) CTRL BATTERY POSITIVE VOLTAGE
RIGHT SUBWOOFER CTRL (+)
SIG GROUND
VIO/BLU WIRE
WHT WIRE
WHT/BRN WIRE
WHT/YEL WIRE
YEL WIRE
YEL/BLK WIRE
YEL/WHT WIRE
Go to component -> Navigation circuit (5 of 5) -> ACTIVE NOISE CANCELLATION MICROPHONE 1 SIGNAL
Wiring diagram active noise cancellation microphone 1 signal (2 of 2)
ACTIVE NOISE CANCELLATION MICROPHONE 1 FEEDBACK SIGNAL
ACTIVE NOISE CANCELLATION MICROPHONE 1 SIGNAL
AUDIO AMPLIFIER
AUTOSAR CAN BUS (+) 5 SERIAL DATA
BLK/WHT WIRE
BLU WIRE
BLU/BLK WIRE
BLU/BRN WIRE
BLU/VIO WIRE
BLU/WHT WIRE
BLU/YEL WIRE
BRN/BLK WIRE
BRN/BLU WIRE
COMPUTER DATA LINES SYSTEM
ETHERNET BUS 6 (-)
FRONT CENTER SPEAKER (-) CTRL
GRN WIRE
GRN/BLK WIRE
GRN/BRN WIRE
GRN/RED WIRE
GRN/VIO WIRE
GRY/BLK WIRE
HOT AT ALL TIMES
LEFT FRONT RADIO SPEAKER INSTRUMENT PANEL
LEFT FRONT SPEAKER 1 (+) CTRL
LEFT FRONT SPEAKER CTRL (+) 1
LEFT INSTRUMENT PANEL WIRING HARNESS JUNCTION BLOCK
NCA WIRE
RADIO FRONT CENTER SPEAKER
RADIO VOLUME COMPENSATOR INTERIOR NOISE MICROPHONE
REAR/LEFT REAR SURROUND SPEAKER (-) CTRL
RED/GRN WIRE
RIGHT FRONT MIDRANGE SPEAKER (+) CTRL
RIGHT FRONT RADIO SIDE DOOR SPEAKER
RIGHT FRONT RADIO SPEAKER INSTRUMENT PANEL
RIGHT FRONT RADIO WINDSHIELD SIDE GARNISH MOLDING SPEAKER
RIGHT FRONT SPEAKER 1 (+) CTRL
RIGHT FRONT SPEAKER CTRL (+) 1
RIGHT SUBWOOFER (-) CTRL BATTERY POSITIVE VOLTAGE
RIGHT SUBWOOFER CTRL (+)
SIG GROUND
VIO/BLU WIRE
WHT WIRE
WHT/BRN WIRE
WHT/YEL WIRE
YEL WIRE
YEL/BLK WIRE
YEL/WHT WIRE
Go to component -> Radio circuit (5 of 5) -> ACTIVE NOISE CANCELLATION MICROPHONE 1 SIGNAL
