Wiring diagram engine performance 7.4l (vin n)s, a/t p/g cutaway (2 of 3) for GMC Forward Control P3500 (1985-1999)

3 121 PNK WIRE ACCY BLK WIRE BLK/RED WIRE BLK/YEL WIRE BRN WIRE BRN/WHT WIRE BULB TEST DISTRIBUTOR (CENTER REAR OF ENGINE) DK BLU WIRE DK GRN/WHT WIRE ENGINE COOLANT TEMPERATURE SENSOR (TOP FRONT OF ENGINE) FUSE BLOCK GAGES FUSE GRY WIRE HOT AT ALL TIMES HOT IN RUN, BULB TEST OR START IGNITION COIL (TOP RIGHT REAR OF ENGINE) IGNITION SWITCH INSTRUMENT CLUSTER KNOCK SENSOR (LEFT REAR OF ENGINE, NEAR OIL PRESSURE SENDER) LOCK OFF LT BLU/WHT WIRE LT GRN WIRE MALFUNCTION (SERVICE ENGINE SOON) INDICATOR MANIFOLD ABSOLUTE PRESSURE SENSOR (ABOVE VALVE COVER) NCA WIRE ORG/ WIRE PNK 22 23 WIRE PNK WIRE PNK/BLK WIRE PPL PPL 20 21 PPL 3 4 PPL/WHT WIRE PROVISIONS FOR TACHOMETER RED WIRE RED/BLK WIRE RUN WIRE TAN/BLK WIRE TCC/BRAKE SWITCH (ON BRAKE PEDAL SUPPORT BRACKET) THROTTLE POSITION SENSOR (ON THROTTLE BODY) TRANS FUSE WHT WIRE WHT/BLK WIRE YEL WIRE YEL/BLK WIRE
