Wiring diagram engine performance 4.3l (vin z)s, a/t commercial chassis for GMC Forward Control P3500 (1985-1999)

3 121 PNK WIRE 4.3L AND 7.4L 5.7L ACCY ALT FUSE BLK WIRE BLK/RED WIRE BLK/YEL WIRE BRN WIRE BRN/WHT WIRE BULB TEST DISTRIBUTOR (CENTER REAR OF ENGINE) DK BLU WIRE DK GRN/WHT WIRE ENGINE COOLANT TEMPERATURE SENSOR (TOP FRONT OF ENGINE) FUSE BLOCK GRY WIRE HOT AT ALL TIMES HOT IN RUN, BULB TEST OR START IGNITION COIL (TOP RIGHT REAR OF ENGINE) IGNITION SWITCH INSTRUMENT CLUSTER KNOCK SENSOR (LEFT REAR OF ENGINE, NEAR OIL PRESSURE SENDER) KNOCK SENSOR MODULE (TOP RIGHT SIDE OF ENGINE) LOCK OFF LT BLU/WHT WIRE LT GRN WIRE MALFUNCTION (SERVICE ENGINE SOON) INDICATOR MANIFOLD ABSOLUTE PRESSURE SENSOR (ABOVE VALVE COVER) NCA WIRE ORG/ WIRE PNK 25 26 WIRE PNK WIRE PNK/BLK WIRE PPL PPL 2 3 4 PPL 23 24 PPL/WHT WIRE PROVISIONS FOR TACHOMETER RED WIRE RED/BLK WIRE RUN WIRE TAN/BLK WIRE TCC/BRAKE SWITCH (ON BRAKE PEDAL SUPPORT BRACKET) THROTTLE POSITION SENSOR (ON THROTTLE BODY) TRANS FUSE WHT WIRE WHT/BLK WIRE YEL WIRE YEL/BLK WIRE

1 2 PPL 1-2 SHIFT SOLENIOD 2-3 SHIFT SOLENIOD 4.3L 5.7L AND 7.4L B/H CONN BLK WIRE BLK/WHT WIRE BLK/YEL WIRE BRN WIRE DATA LINK CONNECTOR (BEHIND LEFT SIDE OF SHIPPING PANEL) DK BLU WIRE DK GRN/WHT WIRE ECM BAT FUSE ELECTRONIC 4-SPEED AUTOMATIC OVERDRIVE TRANSMISSION FUEL PUMP AND SENDER (IN FUEL TANK) FUEL PUMP OIL PRESSURE SWITCH (TOP REAR OF ENGINE) FUEL PUMP PRIME CONNECTOR (NO LOCATION AVAILABLE) FUEL PUMP RELAY (LOWER LEFT SIDE OF SHIPPING PANEL) FUSE BLOCK GRY WIRE HEATED OXYGEN SENSOR (IN EXHAUST MANIFOLD) HOT AT ALL TIMES LT BLU/WHT WIRE LT GRN WIRE LT GRN/BLK WIRE NCA WIRE ORG/ WIRE OXYGEN SENSOR (IN EXHAUST MANIFOLD) PNK WIRE PNK/BLK WIRE PPL PPL/WHT WIRE PRESSURE CONTROL SOLENOID RANGE MODE SELECTOR RED WIRE RED/BLK WIRE SOLENOID TORQUE CONVERTER CLUTCH TRANS- MISSION TEMP SENSOR VEHICLE SPEED SENSOR (LEFT REAR OF TRANSMISSION) VEHICLE SPEED SENSOR BUFFER (BEHIND RIGHT SIDE OF I/P) WHT/BLK WIRE YEL/BLK WIRE
