GMC Forward Control P3500 (1985-1999) seatbelt and lamps alarm module wiring diagram
This page shows the only wiring diagram for the component.seatbelt and lamps alarm module, which is found in the car GMC Forward Control P3500 (1985-1999). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
seatbelt and lamps alarm module wiring diagram (1 of 1)
7.4L
7.4L VIN J 6.5L VIN F
A/C COMPRESSOR RELAY FAN CONTROL RELAY
ALTERNATOR
BATTERY
BATTERY JUNCTION BLOCK (ON FORWARD LEFT SIDE OF THE BULKHEAD)
BLK WIRE
BLU WIRE
BUSS BAR
CONNECTOR FOR DOME LAMP
DATA LINK CONNECTOR
DIESEL
ECM-BAT FUSE 6
ELECTRONIC BRAKE CONTROL MODULE
ENG BAT FUSE 10
FAN CONTROL RELAY GLOW PLUG CONTROLLER
FUEL PUMP RELAY
FUSIBLE LINK
FUSIBLE LINK (10 GA-
FUSIBLE LINK (10 GA-RUST)
FUSIBLE LINK (14 GA-
FUSIBLE LINK (16 GA-
FUSIBLE LINK (18 GA. FUSIBLE LINK (12 GA.
GRY WIRE
HAZARD FLASHER
HEADLAMPS SWITCH
HEADLAMPS SWITCH STOPLAMP SWITCH
HORN DM FUSE 3
HORN RELAY
I/P FUSE BLOCK (MOUNTED ON THE DASH)
IGNITION SWITCH (DIAGRAM 2 OF 4)
ORG/ WIRE
PARK BRAKE PUMP MOTOR RELAY
POWERTRAIN CONTROL MODULE VEHICLE CONTROL MODULE
PWR CIRCUIT BREAKER 2
RED WIRE
SEATBELT AND LAMPS ALARM MODULE
SECONDARY BATTERY (DIESEL ONLY)
STARTER MOTOR
STARTER RELAY
STOP-HAZ FUSE 11
TAIL LAMPS FUSE 7
Go to component -> Power distribution circuit, motor home chassis (1 of 4) -> SEATBELT AND LAMPS ALARM MODULE
