GMC Forward Control P3500 (1985-1999) seat belt tell tale Wiring diagram
This page shows the only wiring diagram for the component.seat belt tell tale, which is found in the car GMC Forward Control P3500 (1985-1999). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram seat belt tell tale (1 of 1)
8 250 40 250 250 LAMP ON INPUT GROUND POWER (BATTERY) SEAT BELT SWITCH
BLK WIRE
GAUGES FUSE 8
GRY WIRE
HORN/DM FUSE 3
HOT AT ALL TIMES
HOT IN RUN AND START
HOT W/ PARK OR HEADLAMPS SWITCH ON
I/P FUSE BLOCK
INSTR LPS FUSE 16
INSTRUMENT CLUSTER
ORG/ WIRE
PNK POWER (IGNITION) WIRE
PNK WIRE
SEAT BELT TELL TALE
SEAT BELT/LAMPS ALARM MODULE (AT THE BOTTOM OF THE I/P FUSE BLOCK)
YEL WIRE
Go to component -> Warning system circuits, motor home chassis -> SEAT BELT TELL TALE
