GMC Forward Control P3500 (1985-1999) seat belt alarm module Wiring diagrams
This page contains all the electrical diagrams for the component. seat belt alarm module, in which he is found in the car GMC Forward Control P3500 (1985-1999). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
seat belt alarm module wiring diagram (1 of 2)
BLK WIRE
BRN WIRE
DK GRN WIRE
DOME LAMP SWITCH
GRY WIRE
HEADLAMPS SWITCH
HIGH DIM
HORN DIM FUSE 3
HOT AT ALL TIMES
I/P FUSE BLOCK
I/P LAMPS DIMMER SWITCH
INSTR LPS FUSE 16
INSTRUMENT CLUSTER
LIGHT SWITCH
OFF HEAD PARK
ORG/ WIRE
PANEL LAMPS SWITCH
PROVISION FOR DOME LAMP
PROVISION FOR MARKER LAMPS
SEAT BELT ALARM MODULE
TAIL LPS FUSE 7
TRANSMISSION RANGE INDICATOR LAMP
WHT WIRE
Go to component -> Interior light circuit, commercial chassis -> SEAT BELT ALARM MODULE
seat belt alarm module wiring diagram (2 of 2)
A/C COMPRESSOR RELAY
ACCESSORY JUNCTION BLOCK (LEFT INTERIOR BULKHEAD, NEAR RELAY BRACKET)
AUXILIARY ENGINE COOLANT FAN RELAY (DIESEL ONLY) GLOW PLUG CONTROLLER (DIESEL)
BATT BUS
BATTERY
BATTERY JUNCTION BLOCK (LEFT SIDE OF ENGINE BULKHEAD)
BLK WIRE
BLU WIRE
DATA LINK CONNECTOR
DIESEL
DOME LAMP (PROVISIONS FOR)
ECM-BAT FUSE 6
ELECTRONIC BRAKE CONTROL MODULE
ENG BAT FUSE 10
FUEL PUMP RELAY VEHICLE CONTROL MODULE
FUSIBLE LINK (10 GA-RUST)
FUSIBLE LINK (12 GA-
FUSIBLE LINK (14 GA-
FUSIBLE LINK (16 GA-
FUSIBLE LINK (18 GA-
GAS
GENERATOR
GRY WIRE
HAZARD LAMP FLASHER
HEADLAMPS SWITCH
HORN DM FUSE 3
HORN RELAY
I/P FUSE BLOCK (DASH PANEL PROVIDED BY BODY BUILDER)
ORG/ WIRE
OTHERS
POWERTRAIN CONTROL MODULE
PWR BUS
PWR CIRCUIT BREAKER
RED WIRE
REMOTE BATTERY ACCESS TERMINAL BLOCK (REAR OF RIGHT RADIATOR CORE SUPPORT PANEL)
SEAT BELT ALARM MODULE
SECONDARY BATTERY (DIESEL ONLY)
STARTER RELAY
STARTER SOLENOID
STOP-HAZ FUSE 11
STUD
TAIL LPS FUSE 7
TO IGNITION SWITCH (DIAGRAM 2 OF 4)
TORQUE CONVERTER CLUTCH, STOPLAMPS SWITCH
TRANSMISSION CONTROL MODULE (A/T ONLY) FUEL PUMP RELAY
W/DELUXE SCHOOL BUS OPTION
Go to component -> Power distribution circuit, commercial chassis (1 of 4) -> SEAT BELT ALARM MODULE
