GMC Forward Control P3500 (1985-1999) license lamps, right rear Wiring diagram
This page shows the only wiring diagram for the component.license lamps, right rear, which is found in the car GMC Forward Control P3500 (1985-1999). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram license lamps, right rear (1 of 1)
1996 VFTC
7.20 +/- 1.20 OHMS
BRN WIRE
DASH LAMPS INPUT
DK GRN WIRE
FROM I/P FUSE BLOCK (TAIL LAMPS FUSE)
GRY WIRE
HEAD OFF PARK
HEADLAMPS SWITCH
I/P LAMPS DIMMER SWITCH
INSTRUMENT CLUSTER
LICENSE LAMPS, LEFT REAR
LICENSE LAMPS, RIGHT REAR
MARKER LAMPS (PROVISIONS FOR)
ORG/ WIRE
PANEL ILLUMINATION
PANEL LAMPS SWITCH
PARK
PARK, TURN SIGNAL (T/S) LAMP LEFT FRONT
PARK, TURN SIGNAL (T/S) LAMP RIGHT FRONT
PRNDL LAMP
SEAT BELT ALARM
SIDE MARKER LAMP LEFT FRONT
SIDE MARKER LAMP RIGHT FRONT
SIDE MARKER LAMP, LEFT REAR (PROVISIONS FOR)
SIDE MARKER LAMP, RIGHT REAR (PROVISIONS FOR)
TAIL
TAIL, STOP/TURN SIGNAL LAMPS LEFT (PROVISIONS FOR)
TAIL, STOP/TURN SIGNAL LAMPS RIGHT (PROVISIONS FOR)
Go to component -> Power distribution circuit, commercial chassis (5 of 5) -> LICENSE LAMPS, RIGHT REAR
