GMC Forward Control P3500 (1985-1999) i/p lamps dimmer switch Wiring diagrams
This page contains all the electrical diagrams for the component. i/p lamps dimmer switch, in which he is found in the car GMC Forward Control P3500 (1985-1999). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
i/p lamps dimmer switch wiring diagram (1 of 3)
BLK WIRE
BRN WIRE
DK GRN WIRE
DOME LAMP SWITCH
GRY WIRE
HEADLAMPS SWITCH
HIGH DIM
HORN DIM FUSE 3
HOT AT ALL TIMES
I/P FUSE BLOCK
I/P LAMPS DIMMER SWITCH
INSTR LPS FUSE 16
INSTRUMENT CLUSTER
LIGHT SWITCH
OFF HEAD PARK
ORG/ WIRE
PANEL LAMPS SWITCH
PROVISION FOR DOME LAMP
PROVISION FOR MARKER LAMPS
SEAT BELT ALARM MODULE
TAIL LPS FUSE 7
TRANSMISSION RANGE INDICATOR LAMP
WHT WIRE
Go to component -> Interior light circuit, commercial chassis -> I/P LAMPS DIMMER SWITCH
i/p lamps dimmer switch wiring diagram (2 of 3)
BLK WIRE
BRN WIRE
DIM HIGH
DK GRN WIRE
DOME LAMP SWITCH
GRY WIRE
HEADLAMPS SWITCH
HORN DM FUSE 3
HOT AT ALL TIMES
I/P FUSE BLOCK
I/P LAMPS DIMMER SWITCH
INSTR LPS FUSE 16
INSTRUMENT CLUSTER
LIGHT SWITCH
OFF HEAD PARK
ORG/ WIRE
PANEL LAMPS SWITCH
PRNDL LAMP
PROVISION FOR DOME LAMP
PROVISION FOR ROOF MARKER LAMPS
SEAT BELT ALARM (BOTTOM OF I/P FUSE BLOCK)
TAIL LPS FUSE 7
WHT WIRE
Go to component -> Interior light circuit, motor home chassis -> I/P LAMPS DIMMER SWITCH
i/p lamps dimmer switch wiring diagram (3 of 3)
1996 VFTC
7.20 +/- 1.20 OHMS
BRN WIRE
DASH LAMPS INPUT
DK GRN WIRE
FROM I/P FUSE BLOCK (TAIL LAMPS FUSE)
GRY WIRE
HEAD OFF PARK
HEADLAMPS SWITCH
I/P LAMPS DIMMER SWITCH
INSTRUMENT CLUSTER
LICENSE LAMPS, LEFT REAR
LICENSE LAMPS, RIGHT REAR
MARKER LAMPS (PROVISIONS FOR)
ORG/ WIRE
PANEL ILLUMINATION
PANEL LAMPS SWITCH
PARK
PARK, TURN SIGNAL (T/S) LAMP LEFT FRONT
PARK, TURN SIGNAL (T/S) LAMP RIGHT FRONT
PRNDL LAMP
SEAT BELT ALARM
SIDE MARKER LAMP LEFT FRONT
SIDE MARKER LAMP RIGHT FRONT
SIDE MARKER LAMP, LEFT REAR (PROVISIONS FOR)
SIDE MARKER LAMP, RIGHT REAR (PROVISIONS FOR)
TAIL
TAIL, STOP/TURN SIGNAL LAMPS LEFT (PROVISIONS FOR)
TAIL, STOP/TURN SIGNAL LAMPS RIGHT (PROVISIONS FOR)
Go to component -> Power distribution circuit, commercial chassis (5 of 5) -> I/P LAMPS DIMMER SWITCH
